Telemecanique XCSDMR7902 Coded Magnetic Safety Switch
Pricing
Request a quote
We reply within 24 hours
Product Description
Telemecanique XCSDMR7902 coded magnetic safety interlock switch for guard-door monitoring.
Technical Specifications
- Manufacturer part number (MPN)
- XCSDMR7902
- EAN / GTIN
- 3666916059456
- Sales unit
- pcs
- Package quantity
- 20 pcs
- Contact configuration
- 2 NC
- Type of actuation
- Magnet
- Type of electric connection
- Cable radial
- Type of switching output
- Relay contact
- Length of sensor
- 38.5 mm
- Diameter sensor
- 30 mm
- Explosion safety category for gas
- None
- Construction type housing
- Cylinder, screw-thread
- Housing material
- Plastic
- Protected switch distance OFF
- 20 mm
- Protected switch distance ON
- 8 mm
- SIL according to IEC 61508
- 3
- Performance level according to EN ISO 13849-1
- Level e
- Max. output current at protected output
- 100 mA
- Ambient temperature
- -25–85 °C
- Mechanical mounting condition for sensor
- Not flat
- Min. output current
- 100 mA
- Rated supply voltage DC
- 24 V
- Voltage type
- AC/DC
- Cross-/short circuit identification possible
- Yes
- Switching distance
- 20 mm
- With monitoring function downstream switching devices
- No
- Suitable for safety functions
- Yes
- With status indication
- No
- Degree of protection (IP)
- IP67K
- Country of origin
- France
Standards & Compliance
- HS Code
- 8536.50
Cross References
- EAN 3666916059456
- SAP 1000254149
- Code 8221334
Product Documentation
More from Telemecanique
Telemecanique
Telemecanique XCSPA493 Safety Limit Switch, 2 NC
Telemecanique
Telemecanique XUSZMD166 Deflection Mirror for Safety Light Curtains, 1750 mm
Telemecanique
Telemecanique XUSL4MB40H181N Type 4 Safety Light Grille with Integrated Muting, 1810 mm protected height
Telemecanique
Telemecanique XCSRD210MDB Safety Limit Switch
Telemecanique
Telemecanique XCMD2106C12 Limit Switch, Cat's Whisker (Spring Rod), Metal Body, M12 connector (5-pin)
Telemecanique
Telemecanique XUSL4E2BB051N Safety Light Grid Type 4, Body Detection, 2 Beams, 510 mm
Telemecanique
Telemecanique XCKT2106G11 Limit Switch, Cat's Whisker (Spring Rod), Plastic Body
Telemecanique
Telemecanique XMLR2D5G1P26 Pressure Sensor with Display, 0–2.5 bar, 4–20 mA + 1× PNP
Technical guides
Catalogue entry last verified: 2026-10-03. A manufacturer datasheet is attached to this entry — confirm application-critical values against it.
Frequently asked questions
- Where can I buy XCSDMR7902?
- XCSDMR7902 can be ordered from cballast.com as a Telemecanique catalogue item: request a quotation on this page or email sales@cballast.com, and the order ships worldwide.
- What is the manufacturer part number for this Telemecanique product?
- The manufacturer part number is XCSDMR7902.
- What is the HS code for XCSDMR7902?
- The customs tariff (HS) code for XCSDMR7902 is 8536.50.
- Who manufactures XCSDMR7902?
- XCSDMR7902 is a Telemecanique product in the Safety & Detection range.
- Is a datasheet available for XCSDMR7902?
- Yes — the XCSDMR7902 datasheet can be viewed and downloaded on this page.
- What is the minimum order quantity for XCSDMR7902?
- The minimum order quantity is 1.
- Is XCSDMR7902 available?
- Yes — XCSDMR7902 is available to order: fulfilment is from supplier stock in cBallast's European network, dispatched directly from the warehouse to the customer, with the exact lead time stated in the quotation (reply within 24 hours).
