Telemecanique XMLR2D5G1N25 Pressure Sensor with Display, 0–2.5 bar, 4–20 mA + 1× NPN

Telemecanique XMLR2D5G1N25 OsiSense XMLR electronic pressure sensor with digital display, measuring range 0–2.5 bar, 4–20 mA + 1× NPN output, G 1/4 A process connection, M12 connector.

Manufacturer part number (MPN)

XMLR2D5G1N25 EAN / GTIN: 3666916020548 Sales unit: pcs Pressure: 2.5 bar Output type: NPN Output signal: 4–20 mA Width: 41 mm Height: 88 mm Depth: 42 mm With display: No Number of normally open contacts as main contact: 1 Number of normally closed contacts as main contact: 1 With manual on/off switch: No Initial setting: 0–2500 hPa End setting: 0–2500 hPa Max. operation pressure: 2500 hPa Explosion-proof: No Degree of protection (IP): IP65/IP67 Initial value measuring range pressure: 13000 Pa Switch off pressure: 0.2–2.5 bar Rated voltage Ue at DC: 24 V Bursting pressure: 12 bar Engaging pressure: 0.13–2.5 bar Electronic version: Yes End value measuring range pressure: 250000 Pa Suitable as 2-point controller: No Suitable as limiter: No Suitable as guard: Yes Max. test pressure: 12 bar Medium temperature: -20–80 °C With hand operation: No Pressure-switching differential: 0.08 bar Max. operating pressure: 2500 hPa Country of origin: Switzerland

HS Code

9026.20

• EAN 3666916020548
• SAP 1000632290
• Code 8308040
