Telemecanique XCSRC11AM12 Safety Limit Switch, M12 connector
Pricing
Request a quote
We reply within 24 hours
Product Description
Telemecanique XCSRC11AM12 safety limit switch with positive opening contacts, M12 connector.
Technical Specifications
- Manufacturer part number (MPN)
- XCSRC11AM12
- EAN / GTIN
- 3666916059319
- Sales unit
- pcs
- Package quantity
- 12 pcs
- Number of protected contact energized outputs
- 8
- Type of actuation
- Magnet
- Type of electric connection
- Connector M12
- Type of switching output
- PNP
- Width sensor
- 15 mm
- Height of sensor
- 108.5 mm
- Length of sensor
- 30 mm
- Explosion safety category for gas
- None
- Explosion safety category for dust
- None
- Construction type housing
- Cuboid
- Coating housing
- Uncoated
- Protected switch distance OFF
- 35 mm
- Protected switch distance ON
- 10 mm
- SIL according to IEC 61508
- 3
- Performance level according to EN ISO 13849-1
- Level e
- Max. output current at protected output
- 60 mA
- Min. output current
- 60 mA
- Voltage type
- DC
- Cross-/short circuit identification possible
- Yes
- Switching distance
- 35 mm
- With monitoring function downstream switching devices
- No
- Suitable for safety functions
- Yes
- With status indication
- No
- Degree of protection (IP)
- IP67
- Country of origin
- France
Standards & Compliance
- HS Code
- 8543.70
Cross References
- EAN 3666916059319
- SAP 1200029248
- Code 81447125
Product Documentation
More from Telemecanique
Telemecanique
Telemecanique XY2CEDA196H7 Emergency Stop Rope Pull Switch, Double-Sided, NPT Entry, 2 × 100 m Rope
Telemecanique
Telemecanique XSAV11801TF Rotation Monitor (Under-Speed Detector) M30, 6–150 rpm, −40 °C
Telemecanique
Telemecanique XZCR1111064D25 Sensor Cable, M12 to M12, 25 m
Telemecanique
Telemecanique XUYR989SP Photoelectric Through-Beam Set, Red Light, PNP, Sn 4 m
Telemecanique
Telemecanique XE2NP2151 Contact Element
Telemecanique
Telemecanique XZCPB1241L2 Sensor Cable, M12 female, 4-pin, PUR, 2 m
Telemecanique
Telemecanique XUSZMD091 Deflection Mirror for Safety Light Curtains, 1060 mm
Telemecanique
Telemecanique XMLR2D5G1P75 Pressure Sensor with Display, 0–2.5 bar, 0–10 V + 1× PNP
Technical guides
Catalogue entry last verified: 2026-10-03. A manufacturer datasheet is attached to this entry — confirm application-critical values against it.
Frequently asked questions
- Where can I buy XCSRC11AM12?
- XCSRC11AM12 can be ordered from cballast.com as a Telemecanique catalogue item: request a quotation on this page or email sales@cballast.com, and the order ships worldwide.
- What is the manufacturer part number for this Telemecanique product?
- The manufacturer part number is XCSRC11AM12.
- What is the HS code for XCSRC11AM12?
- The customs tariff (HS) code for XCSRC11AM12 is 8543.70.
- Who manufactures XCSRC11AM12?
- XCSRC11AM12 is a Telemecanique product in the Safety & Detection range.
- Is a datasheet available for XCSRC11AM12?
- Yes — the XCSRC11AM12 datasheet can be viewed and downloaded on this page.
- What is the minimum order quantity for XCSRC11AM12?
- The minimum order quantity is 1.
- Is XCSRC11AM12 available?
- Yes — XCSRC11AM12 is available to order: fulfilment is from supplier stock in cBallast's European network, dispatched directly from the warehouse to the customer, with the exact lead time stated in the quotation (reply within 24 hours).
