Telemecanique XCSDMR590L01M12 Coded Magnetic Safety Switch, Cylindrical M30, 1NC1NO, M12 connector
Pricing
Request a quote
We reply within 24 hours
Product Description
Telemecanique Preventa XCSDMR590L01M12 coded magnetic safety switch, cylindrical M30 body, 1NC1NO contacts, M12 connector; for position monitoring of guards and doors.
Technical Specifications
- Manufacturer part number (MPN)
- XCSDMR590L01M12
- EAN / GTIN
- 3666916059494
- HS code
- 8536.90
- Sales unit
- pcs
- Package quantity
- 15 pcs
- IP rating
- IP66
- Type of actuation
- Magnet
- Type of electric connection
- Connector M12
- Type of switching output
- Relay contact
- Length of sensor
- 38.5 mm
- Diameter sensor
- 30 mm
- Explosion safety category for gas
- None
- Construction type housing
- Cylinder, screw-thread
- Housing material
- Plastic
- Protected switch distance OFF
- 20 mm
- Protected switch distance ON
- 8 mm
- SIL according to IEC 61508
- 3
- Performance level according to EN ISO 13849-1
- Level e
- Max. output current at protected output
- 100 mA
- Ambient temperature
- -25–85 °C
- Mechanical mounting condition for sensor
- Not flat
- Min. output current
- 100 mA
- Rated supply voltage DC
- 24 V
- Voltage type
- AC/DC
- Cross-/short circuit identification possible
- Yes
- Switching distance
- 20 mm
- With monitoring function downstream switching devices
- No
- Suitable for safety functions
- Yes
- With status indication
- No
- Degree of protection (IP)
- IP67K
- Country of origin
- France
Standards & Compliance
- HS Code
- 8536.90
Cross References
- EAN 3666916059494
- SAP 1000341545
- Code 8976060
Product Documentation
More from Telemecanique
Telemecanique
Telemecanique XUSZMD136 Deflection Mirror for Safety Light Curtains, 1450 mm
Telemecanique
Telemecanique OsiSense XS508B1PAL5 Inductive Proximity Sensor — M8 barrel, Sn 1.5 mm, PNP, NO, pre-wired cable
Telemecanique
Telemecanique XY2CE5A290 Emergency Stop Rope Pull Switch, Right-Hand
Telemecanique
Telemecanique XY2CE2A297 Emergency Stop Rope Pull Switch, with Reset
Telemecanique
Telemecanique XUSL4E14F046NWH Safety Light Curtain Type 4, Finger Detection (14 mm), 460 mm Height
Telemecanique
Telemecanique XCSRZE Safety Limit Switch
Telemecanique
Telemecanique Modular 1-Phase current control relay, 5 A, 2 CO, 2…500 mA,, 24…240 V AC/DC RM35JA31MW
Telemecanique
Telemecanique XT218A1PCM12 Capacitive Proximity Sensor Ø18 mm, PNP, complementary NO+NC, M12 connector
Technical guides
Catalogue entry last verified: 2026-10-03. A manufacturer datasheet is attached to this entry — confirm application-critical values against it.
Frequently asked questions
- Where can I buy XCSDMR590L01M12?
- XCSDMR590L01M12 can be ordered from cballast.com as a Telemecanique catalogue item: request a quotation on this page or email sales@cballast.com, and the order ships worldwide.
- What is the manufacturer part number for this Telemecanique product?
- The manufacturer part number is XCSDMR590L01M12.
- What is the HS code for XCSDMR590L01M12?
- The customs tariff (HS) code for XCSDMR590L01M12 is 8536.90.
- Who manufactures XCSDMR590L01M12?
- XCSDMR590L01M12 is a Telemecanique product in the Safety & Detection range.
- Is a datasheet available for XCSDMR590L01M12?
- Yes — the XCSDMR590L01M12 datasheet can be viewed and downloaded on this page.
- What is the minimum order quantity for XCSDMR590L01M12?
- The minimum order quantity is 1.
- Is XCSDMR590L01M12 available?
- Yes — XCSDMR590L01M12 is available to order: fulfilment is from supplier stock in cBallast's European network, dispatched directly from the warehouse to the customer, with the exact lead time stated in the quotation (reply within 24 hours).
