Telemecanique XCSDMP5005 Coded Magnetic Safety Switch, Large, 2NO/1NC, Pre-wired cable
Pricing
Request a quote
We reply within 24 hours
Product Description
Telemecanique Preventa XCSDMP5005 coded magnetic safety switch, large format, 2NO/1NC contacts, pre-wired cable; for position monitoring of guards and doors.
Technical Specifications
- Manufacturer part number (MPN)
- XCSDMP5005
- EAN / GTIN
- 3666916059883
- HS code
- 8544.42
- Sales unit
- pcs
- Package quantity
- 14 pcs
- Contact configuration
- 2 NO / 1 NC
- Number of protected contact energized outputs
- 3
- Type of actuation
- Magnet
- Type of electric connection
- Cable radial
- Type of switching output
- Relay contact
- Width sensor
- 25 mm
- Height of sensor
- 88 mm
- Length of sensor
- 13 mm
- Explosion safety category for gas
- None
- Explosion safety category for dust
- None
- Construction type housing
- Cuboid
- Housing material
- Plastic
- Coating housing
- Uncoated
- Protected switch distance OFF
- 20 mm
- Protected switch distance ON
- 8 mm
- SIL according to IEC 61508
- 3
- Performance level according to EN ISO 13849-1
- Level e
- Max. output current at protected output
- 100 mA
- Min. output current
- 100 mA
- Voltage type
- AC/DC
- Cross-/short circuit identification possible
- No
- Switching distance
- 20 mm
- With monitoring function downstream switching devices
- No
- Suitable for safety functions
- Yes
- With status indication
- No
- Degree of protection (IP)
- IP66
- Country of origin
- France
Standards & Compliance
- HS Code
- 8544.42
Cross References
- EAN 3666916059883
- SAP 1000341539
- Code 8976040
Product Documentation
More from Telemecanique
Telemecanique
Telemecanique XCSE5331 Safety Limit Switch with Solenoid 120 V 1NC+2NO
Telemecanique
Telemecanique XUSZMF138 Deflection Mirror for Safety Light Curtains, 1385 mm
Telemecanique
Telemecanique XUM5APXBM8 Photoelectric Sensor, Diffuse with Background Suppression, Sn 1.5 m, PNP, M8 connector
Telemecanique
Stainless Angle Bracket Ø12 mm
XSZBS12
Telemecanique
Telemecanique XMLP001GC21F Pressure Transmitter, 0.5–4.5 V ratiometric, G 1/4
Telemecanique
Telemecanique OsiSense XS508B1PBL2 Inductive Proximity Sensor — M8 barrel, Sn 1.5 mm, PNP, NC, pre-wired cable (2 m)
Telemecanique
Telemecanique ZCKE64 Operating Head for ZCK Limit Switches
Telemecanique
Telemecanique XUM9ANXBM8 Photoelectric Sensor, Retroreflective, Sn 6.7 m, NPN, M8 connector
Technical guides
Catalogue entry last verified: 2026-10-03. A manufacturer datasheet is attached to this entry — confirm application-critical values against it.
Frequently asked questions
- Where can I buy XCSDMP5005?
- XCSDMP5005 can be ordered from cballast.com as a Telemecanique catalogue item: request a quotation on this page or email sales@cballast.com, and the order ships worldwide.
- What is the manufacturer part number for this Telemecanique product?
- The manufacturer part number is XCSDMP5005.
- What is the HS code for XCSDMP5005?
- The customs tariff (HS) code for XCSDMP5005 is 8544.42.
- Who manufactures XCSDMP5005?
- XCSDMP5005 is a Telemecanique product in the Safety & Detection range.
- Is a datasheet available for XCSDMP5005?
- Yes — the XCSDMP5005 datasheet can be viewed and downloaded on this page.
- What is the minimum order quantity for XCSDMP5005?
- The minimum order quantity is 1.
- Is XCSDMP5005 available?
- Yes — XCSDMP5005 is available to order: fulfilment is from supplier stock in cBallast's European network, dispatched directly from the warehouse to the customer, with the exact lead time stated in the quotation (reply within 24 hours).
