Telemecanique XCSDMC5912 Magnetic Safety Switch, 1 NO + 1 NC, 2 m cable, with LED
Pricing
Request a quote
We reply within 24 hours
Product Description
Telemecanique XCSDMC5912 magnetic safety interlock switch for guard-door monitoring, 1 NO + 1 NC contacts, 2 m cable, with LED.
Technical Specifications
- Manufacturer part number (MPN)
- XCSDMC5912
- EAN / GTIN
- 3666916060100
- Sales unit
- pcs
- Package quantity
- 20 pcs
- Contact configuration
- 1 NO + 1 NC
- Number of contact energized outputs with signalling function
- 1
- Number of protected contact energized outputs
- 2
- Type of actuation
- Magnet
- Type of electric connection
- Cable radial
- Type of switching output
- Relay contact
- Width sensor
- 16 mm
- Height of sensor
- 51 mm
- Length of sensor
- 7 mm
- Explosion safety category for gas
- None
- Explosion safety category for dust
- None
- Construction type housing
- Cuboid
- Housing material
- Plastic
- Coating housing
- Uncoated
- Protected switch distance OFF
- 15 mm
- Protected switch distance ON
- 5 mm
- SIL according to IEC 61508
- 3
- Performance level according to EN ISO 13849-1
- Level e
- Max. output current at protected output
- 100 mA
- Ambient temperature
- -25–85 °C
- Min. output current
- 100 mA
- Rated supply voltage DC
- 24 V
- Voltage type
- AC/DC
- Cross-/short circuit identification possible
- No
- Switching distance
- 15 mm
- With monitoring function downstream switching devices
- No
- Suitable for safety functions
- Yes
- With status indication
- No
- Degree of protection (IP)
- IP66
- Country of origin
- France
Standards & Compliance
- HS Code
- 8536.50
Cross References
- EAN 3666916060100
- SAP 1000032405
- Code 8250985
Product Documentation
More from Telemecanique
Telemecanique
Telemecanique XCSDMP7012 Magnetic Safety Switch, 2 NO + 1 NC, 2 m cable, with LED
Telemecanique
Telemecanique OsiSense XS130BHNBL2 Inductive Proximity Sensor — M30 barrel, Sn 15 mm, NPN, NC, pre-wired cable (2 m)
Telemecanique
Telemecanique XMLR001G1N26 Pressure Sensor with Display, 0–1 bar, 4–20 mA + 1× NPN
Telemecanique
Telemecanique XXA18S1PM12 Ultrasonic Sensor, M18, Sn 1 m, PNP, right-angle head, M12 connector
Telemecanique
Telemecanique XMLR001G1N25 Pressure Sensor with Display, 0–1 bar, 4–20 mA + 1× NPN
Telemecanique
Telemecanique OsiSense XS1N12PC410 Inductive Proximity Sensor — M12 barrel, Sn 2 mm, PNP, NO or NC, pre-wired cable (2 m)
Telemecanique
Telemecanique OsiSense XS130BHNAM12 Inductive Proximity Sensor — M12 barrel, Sn 15 mm, NPN, NO, M12 connector (4-Pin)
Telemecanique
Telemecanique XXS30B4VM12 Ultrasonic Sensor, M30, Sn 4 m, 0–10 V, M12 connector
Technical guides
Catalogue entry last verified: 2026-10-03. A manufacturer datasheet is attached to this entry — confirm application-critical values against it.
Frequently asked questions
- Where can I buy XCSDMC5912?
- XCSDMC5912 can be ordered from cballast.com as a Telemecanique catalogue item: request a quotation on this page or email sales@cballast.com, and the order ships worldwide.
- What is the manufacturer part number for this Telemecanique product?
- The manufacturer part number is XCSDMC5912.
- What is the HS code for XCSDMC5912?
- The customs tariff (HS) code for XCSDMC5912 is 8536.50.
- Who manufactures XCSDMC5912?
- XCSDMC5912 is a Telemecanique product in the Safety & Detection range.
- Is a datasheet available for XCSDMC5912?
- Yes — the XCSDMC5912 datasheet can be viewed and downloaded on this page.
- What is the minimum order quantity for XCSDMC5912?
- The minimum order quantity is 1.
- Is XCSDMC5912 available?
- Yes — XCSDMC5912 is available to order: fulfilment is from supplier stock in cBallast's European network, dispatched directly from the warehouse to the customer, with the exact lead time stated in the quotation (reply within 24 hours).
