Telemecanique OsiSense XS130BHNAM12 Inductive Proximity Sensor — M12 barrel, Sn 15 mm, NPN, NO, M12 connector (4-Pin)
Pricing
Request a quote
We reply within 24 hours
Product Description
Telemecanique XS130BHNAM12 is an OsiSense XS inductive proximity sensor in an M12 nickel-plated brass threaded barrel, with a nominal sensing distance (Sn) of 15 mm and a flush-mountable (shielded) sensing face. It provides a NPN (3-wire DC) output, switching NO (normally open), via M12 connector (4-pin). IP67 protection, operating range -25 °C to +70 °C, with output-state LED indication. Conforms to IEC 60947-5-2.
Technical Specifications
- Manufacturer part number (MPN)
- XS130BHNAM12
- EAN / GTIN
- 3666916017425
- Product type
- OsiSense XS inductive proximity sensor
- Housing
- M12 cylindrical threaded barrel (Nickel-plated brass)
- Mounting
- flush-mountable (shielded)
- Nominal sensing distance Sn
- 15 mm
- Output
- NPN (3-wire DC)
- Switching function
- NO (normally open)
- Connection
- M12 connector (4-pin)
- Degree of protection
- IP67
- Operating temperature
- -25 °C to +70 °C
- Conforms to
- IEC 60947-5-2
- HS code
- 8536.50
- Sales unit
- pcs
- Package quantity
- 48 pcs
Standards & Compliance
- Standard
- IEC 60947-5-2
- Material
- Nickel-plated brass
- Temperature Range
- -25 °C to +70 °C
- IP Rating
- IP67
- HS Code
- 8536.50
Cross References
- EAN 3666916017425
Product Documentation
More from Telemecanique
Telemecanique
Telemecanique XXS30B4VM12 Ultrasonic Sensor, M30, Sn 4 m, 0–10 V, M12 connector
Telemecanique
Telemecanique OsiSense XS630B3DAM12 Inductive Proximity Sensor — M30 barrel, Sn 15 mm, 2-Wire DC, NO, M12 connector (4-Pin)
Telemecanique
Telemecanique XUBLAKCNM12T Laser Photoelectric Sensor M18, Plastic, M12 connector
Telemecanique
12-48DC PNP Sn=40mm NO/NC
XSDH407339
Telemecanique
Telemecanique XZCPV1865L10 Sensor Cable, M8 female, 3-pin, PVC, 10 m
Telemecanique
Telemecanique XZCP1965L10 Sensor Cable, M8 female angled, 3-pin, 10 m
Telemecanique
Telemecanique XMLR2D5G1N75 Pressure Sensor with Display, 0–2.5 bar, 0–10 V + 1× NPN
Telemecanique
Telemecanique XUSL4E30H061LWC Safety Light Curtain Type 4, Hand Detection (30 mm), 610 mm Height
Technical guides
- Inductive Proximity Sensor Cross-Reference — Telemecanique OsiSense XS, Carlo Gavazzi ICB, Omron E2E, Eaton E57, Turck, Pepperl+Fuchs by Housing, Sensing Distance and Output
- Emergency Stop Rope Pull Switches — Covering Conveyors to EN ISO 13850 with XY2C
- Inductive Proximity Sensors — Diameter, Sensing Distance, Flush Mounting, PNP/NPN and NO/NC Explained
Catalogue entry last verified: 2026-09-29. A manufacturer datasheet is attached to this entry — confirm application-critical values against it.
Frequently asked questions
- Where can I buy XS130BHNAM12?
- XS130BHNAM12 can be ordered from cballast.com as a Telemecanique catalogue item: request a quotation on this page or email sales@cballast.com, and the order ships worldwide.
- What is the manufacturer part number for this Telemecanique product?
- The manufacturer part number is XS130BHNAM12.
- What is the HS code for XS130BHNAM12?
- The customs tariff (HS) code for XS130BHNAM12 is 8536.50.
- Who manufactures XS130BHNAM12?
- XS130BHNAM12 is a Telemecanique product in the Sensors & Instrumentation range.
- Is a datasheet available for XS130BHNAM12?
- Yes — the XS130BHNAM12 datasheet can be viewed and downloaded on this page.
- What is the minimum order quantity for XS130BHNAM12?
- The minimum order quantity is 1.
- Is XS130BHNAM12 available?
- Yes — XS130BHNAM12 is available to order: fulfilment is from supplier stock in cBallast's European network, dispatched directly from the warehouse to the customer, with the exact lead time stated in the quotation (reply within 24 hours).
