SKF YAR216-2F Insert bearing (YAR / YET / YSA / YEL)

SKF YAR216-2F insert bearing (yar / yet / ysa / yel). Spherical-outer-ring insert ball bearing suited to drop-in mounting in a pillow-block, flanged, take-up or tapped-base housing. Set-screw (YAR), eccentric locking collar (YET), adapter-sleeve (YSA), or grub-screw double-lock (YEL) shaft attachment per suffix. Sealed for life with grease; regreasable variants add a lubrication nipple to the outer ring.

Type

Insert bearing (YAR / YET / YSA / YEL)

Designation

SKF YAR216-2F

Bore d

80 mm

HS code

8482.10

Shaft diameter

80 mm

Bore diameter

80 mm

Outside diameter

140 mm

Width, total

77.8 mm

Width, inner ring

77.8 mm

Width, outer ring

30 mm

Basic dynamic load rating

72.8 kN

Basic static load rating

53 kN

Limiting speed

2400 r/min

Note

Limiting speed with shaft tolerance h6

Retaining feature, inner ring

Set screws

Bore type

Cylindrical

Rolling elements

Balls

Outer ring type

Spherical

Inner ring extension

On both sides

Cage

Non-metallic

Rubber seating ring

Without

Material, bearing

Bearing steel

Coating

Without

Sealing

Seal and flinger on both sides

Sealing type

Contact, standard

Lubricant

Grease

Relubrication feature

With

Product net weight

2.45 kg

eClass code

23-05-08-02

UNSPSC code

31171536

Standard

SKF designation convention (see description for governing ISO / DIN)

Material

As declared by SKF designation suffix

Temperature Range

Per SKF product data

HS Code

8482.10

• NTN 2162
• NSK 2162
• FAG 2162
• Koyo 2162
• ASAHI 2162
• Equivalent: 2162 (NTN)
• Equivalent: 2162 (NSK)
• Equivalent: 2162 (FAG)
• Equivalent: 2162 (Koyo)
• Equivalent: 2162 (ASAHI)
