SKF PHFFX90-45X55 Keyless shaft bushing / locking assembly
Pricing
Request a quote
We reply within 24 hours
Product Description
SKF PHFFX90-45X55 keyless shaft bushing / locking assembly. Frictional shaft-to-hub coupling that transmits torque without a key or splined joint, by radial-elastic clamping between the shaft and hub. Executed as a double-taper collet (self-centring), a single-taper Ringfeder-style assembly, or a stepped-piston hydraulic clamp. Removed and re-installed non-destructively; excellent choice for high-precision or high-torque locations where a keyway would fatigue the shaft.
Technical Specifications
- Type
- Keyless shaft bushing / locking assembly
- Designation
- SKF PHFFX90-45X55
- HS code
- 8483.60
- Bore diameter
- 45 mm
- Outside diameter
- 55 mm
- Width, total
- 46 mm
- Contact width
- 30 mm
- Bushing number
- FX90
- Category
- Keyless bushings
- Clamp screws nut
- KM10
- Number of clamp screws
- 0
- Product net weight
- 0.39 kg
- eClass code
- 23-05-19-01
- UNSPSC code
- 31171605
Standards & Compliance
- Standard
- SKF designation convention
- Material
- As declared by SKF designation suffix
- Temperature Range
- Per SKF product data
- HS Code
- 8483.60
Cross References
- Ringfeder 904555
- Fenner 904555
- KTR 904555
- Tollok 904555
- Equivalent: 904555 (Ringfeder)
- Equivalent: 904555 (Fenner)
- Equivalent: 904555 (KTR)
- Equivalent: 904555 (Tollok)
Compatibility & Fitment
Interchange with peer OEM equivalents on identical boundary plan and execution — confirm cage, clearance, sealing and precision-class suffix before substitution.
Product Documentation
More from SKF
SKF
SKF SIR120ES Rod end (spherical plain bearing with threaded eye)
SKF
SKF 773.7X806.7X44DOCR60 Metal face seal (Duo-Cone / mud seal)
SKF
SKF 2308EM Self-aligning ball bearing (12XX / 13XX / 22XX)
SKF
SKF NJ213ECJ/C3 Single-row cylindrical roller bearing (NU / N / NJ / NUP)
SKF
SKF 99845 SKF Speedi-Sleeve shaft wear sleeve
SKF
SKF C5020V CARB toroidal roller bearing (C xxxx)
SKF
SKF COP.SR85M Cooper split roller bearing
