SKF F2BC20M-CPSS-DFH Flanged ball bearing unit (UCF / UCFC / UCFL)

SKF F2BC20M-CPSS-DFH flanged ball bearing unit (ucf / ucfc / ucfl). Square four-bolt (UCF), round three-bolt (UCFC) or oval two-bolt (UCFL) flanged housing pre-assembled with a spherical-outer-ring insert bearing. Absorbs shaft-to-housing misalignment on assembly. Set-screw shaft attachment on standard UC-series insert; eccentric-collar (UEL) or adapter-sleeve (UK) variants available. Dimensioned to ISO 3228 / DIN 626.

Type

Flanged ball bearing unit (UCF / UCFC / UCFL)

Designation

SKF F2BC20M-CPSS-DFH

HS code

8483.20

Shaft diameter

20 mm

Housing overall width

27 mm

Centre distance between bolt holes

90 mm

Bearing width, total

25.3 mm

Attachment bolt diameter

10 mm

Basic dynamic load rating

10.8 kN

Basic static load rating

6.55 kN

Limiting speed

700 r/min

Housing type

Flanged

Flanged housing type

Oval

Number of bolt holes for fasteners

2

Fastening bolt hole type

Plain

Retaining feature, inner ring

Set screws

Bore type

Cylindrical

Rubber seating ring

Without

Material, housing

Composite for the SKF Food Line

Material, bearing

Stainless steel

Coating

Without

Sealing, bearing

Seal on both sides and flinger on one side

Sealing type

Contact, gutter

Sealing, unit

End cover and back seal

Lubricant

Grease

Relubrication hole

Without

Grease fitting

Without

Product net weight

0.221 kg

eClass code

23-05-08-02

UNSPSC code

31171536

Standard

SKF designation convention

Material

As declared by SKF designation suffix

Temperature Range

Per SKF product data

HS Code

8483.20
