SKF BT1B332787/HA4 Single-row tapered roller bearing

SKF BT1B332787/HA4 single-row tapered roller bearing. Single-row tapered roller bearing designed to take combined heavy radial and one-direction axial load. Cone (inner ring), cup (outer ring) and rollers converge at a common apex on the bearing axis. Two bearings are always mounted in opposition. Metric dimensions per ISO 355; imperial to ANSI/ABMA 19.1.

Type

Single-row tapered roller bearing

Designation

SKF BT1B332787/HA4

HS code

8482.20

Bore diameter

680 mm

Outside diameter

1000 mm

Width, total

190 mm

Width, inner ring

188 mm

Width, outer ring

140 mm

Contact angle

16.1 °

Basic dynamic load rating

5610 kN

Basic static load rating

12700 kN

Reference speed

360 r/min

Limiting speed

500 r/min

Bearing part

Complete bearing

Number of rows

1

Locating feature, bearing outer ring

Without

Bore type

Cylindrical

Arrangement of contact angle (double-row bearing)

Not applicable

Matched arrangement

No

Coating

Without

Sealing

Without

Lubricant

None

Relubrication feature

Without

Unit system

Metric

Candidate for remanufacturing

Yes

Indicative carbon footprint for new product

1794 kg CO2e

Indicative carbon footprint for remanufactured product

596 kg CO2e

Product net weight

485 kg

eClass code

23-05-09-10

Standard

SKF designation convention

Material

As declared by SKF designation suffix

Temperature Range

Per SKF product data

HS Code

8482.20

• Timken 13327874
• NSK 13327874
• NTN 13327874
• FAG 13327874
• Koyo 13327874
• Equivalent: 13327874 (Timken)
• Equivalent: 13327874 (NSK)
• Equivalent: 13327874 (NTN)
• Equivalent: 13327874 (FAG)
• Equivalent: 13327874 (Koyo)
