SKF BT1B334140/HA4 Single-row tapered roller bearing

SKF BT1B334140/HA4 single-row tapered roller bearing. Single-row tapered roller bearing designed to take combined heavy radial and one-direction axial load. Cone (inner ring), cup (outer ring) and rollers converge at a common apex on the bearing axis. Two bearings are always mounted in opposition. Metric dimensions per ISO 355; imperial to ANSI/ABMA 19.1.

Type

Single-row tapered roller bearing

Designation

SKF BT1B334140/HA4

HS code

8482.20

Bore diameter

660.4 mm

Outside diameter

1000 mm

Width, total

152.4 mm

Width, inner ring

142.24 mm

Width, outer ring

113.665 mm

Contact angle

15.7 °

Basic dynamic load rating

4652 kN

Basic static load rating

9500 kN

Reference speed

360 r/min

Limiting speed

480 r/min

Bearing part

Complete bearing

Number of rows

1

Locating feature, bearing outer ring

Without

Bore type

Cylindrical

Arrangement of contact angle (double-row bearing)

Not applicable

Matched arrangement

No

Coating

Without

Sealing

Without

Lubricant

None

Relubrication feature

Without

Unit system

Inch

Candidate for remanufacturing

Yes

Indicative carbon footprint for new product

1504 kg CO2e

Indicative carbon footprint for remanufactured product

500 kg CO2e

Product net weight

407 kg

eClass code

23-05-09-10

Standard

SKF designation convention

Material

As declared by SKF designation suffix

Temperature Range

Per SKF product data

HS Code

8482.20
