SKF BBY-5514 Insert bearing (YAR / YET / YSA / YEL)

SKF BBY-5514 insert bearing (yar / yet / ysa / yel). Spherical-outer-ring insert ball bearing suited to drop-in mounting in a pillow-block, flanged, take-up or tapped-base housing. Set-screw (YAR), eccentric locking collar (YET), adapter-sleeve (YSA), or grub-screw double-lock (YEL) shaft attachment per suffix. Sealed for life with grease; regreasable variants add a lubrication nipple to the outer ring.

Type

Insert bearing (YAR / YET / YSA / YEL)

Designation

SKF BBY-5514

HS code

8482.10

Bore diameter

31.773 mm

Outside diameter

62 mm

Width, total

24 mm

Width, inner ring

38.1 mm

Width, outer ring

16 mm

Basic dynamic load rating

19.5 kN

Basic static load rating

11.2 kN

Limiting speed

0 r/min

Retaining feature, inner ring

Interference fit

Bore type

Cylindrical

Rolling elements

Balls

Outer ring type

Spherical

Inner ring extension

On both sides

Cage

Non-metallic

Rubber seating ring

Without

Material, bearing

Bearing steel

Coating

Without

Sealing

Without

Lubricant

None

Relubrication feature

Without

Product net weight

0.21 kg

eClass code

23-05-08-02

UNSPSC code

31171536

Standard

SKF designation convention (see description for governing ISO / DIN)

Material

As declared by SKF designation suffix

Temperature Range

Per SKF product data

HS Code

8482.10

• NTN 5514
• NSK 5514
• FAG 5514
• Koyo 5514
• ASAHI 5514
• Equivalent: 5514 (NTN)
• Equivalent: 5514 (NSK)
• Equivalent: 5514 (FAG)
• Equivalent: 5514 (Koyo)
• Equivalent: 5514 (ASAHI)
