Siemens LOGO! DM8 24R

Siemens 6ED1055-1CB10-0BA2 — LOGO! logic module. Compact micro-controller for small automation and building-services tasks. LOGO! DM8 24R. Siemens genuine. Siemens i/o modules for industrial and marine service. Fits listed models.

Brand

Siemens

Part number

6ED1055-1CB10-0BA2

Category

I/O Modules

Approvals

CE, UL, cUL, CSA, FM, ATEX II 3G (Ex nA variants), IECEx, RCM, EAC, KC, CCC, DNV, ABS, LR, BV, ClassNK

Mounting

on 35 mm DIN rail, 4 spacing units wide

Rated value (DC)

24 V DC

Permissible range, lower limit (DC)

20.4 V

Permissible range, upper limit (DC)

28.8 V

Number of digital inputs

8

Type of input voltage

DC

Input voltage for signal "0"

< 5 V DC

Input voltage for signal "1"

> 12 V DC

Input current for signal "1", typ.

2 mA

Input delay for standard inputs at "0" to "1", max.

1.5 ms

Number of digital outputs

8

Short-circuit protection

Yes

Output current for signal "1" rated value

0.3 A

Switching frequency with resistive load, max.

10 Hz

Switching frequency with inductive load, max.

0.5 Hz

Emission of radio interference acc. to EN 55 011 Limit class B, for use in residential areas

Yes

IP degree of protection

IP20

CE mark

Yes

CSA approval

Yes

UL approval

Yes

FM approval

Yes

Developed in accordance with IEC 61131

Yes

Marine approval

Yes

Ambient temperature during operation, min.

-20 °C; No condensation

Ambient temperature during operation, max.

55 °C

Dimensions — Width

71.5 mm

Dimensions — Height

90 mm

Dimensions — Depth

58 mm

EAN

4034106029487

Classification / Approval

CE, UL, cUL, CSA, FM, ATEX II 3G (Ex nA variants), IECEx, RCM, EAC, KC, CCC, DNV, ABS, LR, BV, ClassNK

HS Code

8537.10
