Siemens SITOP PSU100C 1AC/DC/12 V DC/6.5 A Regulated Power Supply

Siemens 6EP1322-5BA10 SITOP DC power supply. DIN-rail primary-switched regulated 24 V DC power supply for automation panels. SITOP PSU100C 12 V/6.5 A regulated power supply, input voltage: AC 120-230 V (DC 110-300 V).

Manufacturer part number (MPN)

6EP1322-5BA10 EAN / GTIN: 4025515152644 Sales unit: pcs Type of the power supply network: 1-phase AC or DC Supply voltage at AC minimum rated value: 100 V Supply voltage at AC maximum rated value: 230 V Supply voltage at AC initial value: 85 V Supply voltage at AC full-scale value: 264 V Input voltage at DC: 110 - 300 V Overvoltage overload capability: 2.3 × Vin rated, 1.3 ms Buffering time for rated value of the output current in the event of power failure minimum: 20 ms Operating condition of the mains buffering: at Vin = 230 V Line frequency: 50/60 Hz Input current at rated input voltage 100 V: 1.6 A Input current at rated input voltage 230 V: 0.8 A Current limitation of inrush current at 25 °C maximum: 31 A I2t value maximum: 3 A²·s Fuse protection type in the feeder: Recommended miniature circuit breaker: from 16 A characteristic B or from 10 A characteristic C Output voltage at DC rated value: 12 V Output voltage at output 1 at DC r

HS Code

8504.40

• EAN 4025515152644
• SAP 1000350939
• Code 81058836
