Siemens SIRIUS 3RV20 motor protection circuit breaker, frame size S00 3RV2011-1JA10
Pricing
Request a quote
We reply within 24 hours
Product Description
Siemens 3RV2011-1JA10 — SIRIUS 3RV20 motor protection circuit breaker, frame size S00. Rated 0.11 to 16 A adjustable, up to 100 kA short-circuit breaking, IEC 60947-4-1 type-2 coordination with paired 3RT2 contactor. 11 to 16 A adjustable, up to 100 kA short-circuit breaking, IEC 60947-4-1 type-2 coordination with paired 3RT2 contactor. Motor protection circuit breaker rated current 7-10A.
Technical Specifications
- Manufacturer part number (MPN)
- 3RV2011-1JA10
- EAN / GTIN
- 4011209712492
- HS code
- 8536.90
- Sales unit
- pcs
- Package quantity
- 28 pcs
- Width
- 45 mm
- Height
- 97 mm
- Depth
- 97 mm
- Rated operation power at AC-3, 400 V
- 4 kW
- Rated permanent current Iu
- 10 A
- Number of poles
- 3
- Power loss
- 9.25 W
- Degree of protection (IP)
- IP20
- With thermal overload protection
- Yes
- Type of electrical connection of main circuit
- Screw connection
- Switch off technique
- Magnetic
- Rated operation power at AC-3, 230 V
- 2.2 kW
- Rated short-circuit breaking capacity Icu at 400 V, AC
- 100 kA
- Device construction
- Built-in device fixed built-in technique
- Country of origin
- Germany
Standards & Compliance
- HS Code
- 8536.90
Cross References
- EAN 4011209712492
- SAP 1000099972
- Code 8594408
Product Documentation
