Siemens 3VA1196-3ED32-0AA0 MCCB 3VA11 25 kA 3-Pole TM210 Thermal/Instantaneous 16 A
Pricing
Request a quote
We reply within 24 hours
Product Description
Siemens 3VA1196-3ED32-0AA0 moulded-case circuit breaker from the 3VA11 range, 25 kA breaking capacity at 400 V / 50 Hz, 3-pole with a TM210 fixed thermal-magnetic trip unit and fast instantaneous release. Rated 16 A with bolted power terminals in a withdrawable slide-in construction.
Technical Specifications
- Manufacturer part number (MPN)
- 3VA1196-3ED32-0AA0
- EAN / GTIN
- 4042948812082
- HS code
- 8536.90
- Sales unit
- pcs
- Rated current
- 16 A
- Number of poles
- 3
- Breaking capacity
- 25 kA
- Rated permanent current Iu
- 16 A
- With integrated under voltage release
- No
- Power loss
- 10.6 W
- Degree of protection (IP)
- IP40
- Position of connection for main current circuit
- Front side
- Type of electrical connection of main circuit
- Screw connection
- Type of control element
- Rocker lever
- With switched-off indicator
- No
- Rated short-circuit breaking capacity Icu at 400 V, 50 Hz
- 25 kA
- Device construction
- Built-in device slide-in technique (withdrawable)
- Country of origin
- Czechia
Standards & Compliance
- HS Code
- 8536.90
Cross References
- EAN 4042948812082
- SAP 1000731606
- Code 8356854
Product Documentation
More from Siemens
Siemens
Siemens Sinamics V20 EMC Termineringskit for framesize A
6SL3266-1AA00-0VA0
Siemens
Siemens Load-break switch 125A,size 2,3-Pole,operation side left-hand,box terminal for Cu cable
3KD3234-2NE10-0
Siemens
Siemens SENTRON 3VA9111-0WJ30 — Insulation backplate, 3-Pole, 3VA10 / 3VA11
Siemens
Siemens SENTRON 5SY4604-7 Miniature Circuit Breaker 3+N-Pole C4A 10KA
Siemens
Siemens Sinamics G120D Power Module PM250D with Built-in Filter Kl 6SL3525-0PE24-0AA1
Siemens
Siemens Mounting Kit for bracket of cable trunking
8PQ6000-0BA16
Siemens
Siemens 3VA11, 25KA, 4-Pole, TM240, IN=40A,IR=28A 3VA11403GF460AA0
Siemens
Siemens SIRIUS Motor protection circuit breaker 42 3RV2031-4WA15
Technical guides
Catalogue entry last verified: 2026-09-29. A manufacturer datasheet is attached to this entry — confirm application-critical values against it.
Frequently asked questions
- Where can I buy 3VA1196-3ED32-0AA0?
- 3VA1196-3ED32-0AA0 can be ordered from cballast.com as a Siemens catalogue item: request a quotation on this page or email sales@cballast.com, and the order ships worldwide.
- What is the manufacturer part number for this Siemens product?
- The manufacturer part number is 3VA1196-3ED32-0AA0.
- What is the HS code for 3VA1196-3ED32-0AA0?
- The customs tariff (HS) code for 3VA1196-3ED32-0AA0 is 8536.90.
- Who manufactures 3VA1196-3ED32-0AA0?
- 3VA1196-3ED32-0AA0 is a Siemens product in the Electrical Components range.
- Is a datasheet available for 3VA1196-3ED32-0AA0?
- Yes — the 3VA1196-3ED32-0AA0 datasheet can be viewed and downloaded on this page.
- What is the minimum order quantity for 3VA1196-3ED32-0AA0?
- The minimum order quantity is 1.
- Is 3VA1196-3ED32-0AA0 available?
- Yes — 3VA1196-3ED32-0AA0 is available to order: fulfilment is from supplier stock in cBallast's European network, dispatched directly from the warehouse to the customer, with the exact lead time stated in the quotation (reply within 24 hours).
