Siemens SIRIUS 3RB3 Electronic Overload Relay 1...4 A, Size S00, Class 10E, Main Screw, Aux Screw

Siemens 3RB3016-1PB0 Electronic Overload Relay 1-4A.

Manufacturer part number (MPN)

3RB3016-1PB0

EAN / GTIN

4011209748637

Sales unit

pcs

power loss [W] for rated value of the current at AC in hot operating state

0.1 W

insulation voltage with degree of pollution 3 at AC rated value

690 V

surge voltage resistance rated value

6 kV

maximum permissible voltage for protective separation – in networks with ungrounded star point between main and auxiliary circuit

600 V

maximum permissible voltage for protective separation – in networks with grounded star point between main and auxiliary circuit

690 V

thermal current

4 A

recovery time after overload trip – with automatic reset typical

3 min

Net Weight

0.213 kg

installation altitude at height above sea level maximum

2 000 m

ambient temperature – during operation

-25 ... +60 °C

ambient temperature – during storage

-40 ... +80 °C

ambient temperature – during transport

-40 ... +80 °C

temperature compensation

-25 ... +60 °C

relative humidity during operation

10 ... 95 %

adjustable current response value current of the current-dependent overload release

1 ... 4 A

operating voltage – rated value

690 V

operating frequency rated value

50 ... 60 Hz

operational current rated value

4 A

operational current at AC-3e at 400 V rated value

4 A

operating power – for 3-phase motors at 400 V at 50 Hz

0.37 ... 1.5 kW

operating power – for AC motors at 500 V at 50 Hz

0.37 ... 2.2 kW

operating power – for AC motors at 690 V at 50 Hz

0.55 ... 3 kW

operational current of auxiliary contacts at AC-15 – at 24 V

4 A

operational current of auxiliary contacts at AC-15 – at 230 V

3 A

operational current of auxiliary contacts at DC-13 – at 24 V

2 A

operational current of auxiliary contacts at DC-13 – at 110 V

0.3 A

operational current of auxiliary contacts at DC-13 – at 220 V

0.11 A

full-load current (FLA) for 3-phase AC motor – at 480 V rated value

4 A

full-load current (FLA) for 3-phase AC motor – at 600 V rated value

4 A

Installation/ mounting/ dimensions – height

79 mm

Installation/ mounting/ dimensions – width

45 mm

Installation/ mounting/ dimensions – depth

73 mm

type of connectable conductor cross-sections for main contacts – solid

1x (0.5 ... 4 mm²), 2x (0.5 ... 1.5 mm²), 2x (0.75 ... 4 mm²)

Mounting method

Direct attachment

Width

45 mm

Height

79 mm

Depth

73 mm

Number of auxiliary contacts as normally open contact

1

Number of auxiliary contacts as normally closed contact

1

Release class

CLASS 10

Type of electrical connection of main circuit

Screw connection

Reset function input

No

Reset function automatic

Yes

Country of origin

Czechia

HS Code

8536.49
