Siemens 5SU13246FA25
Pricing
Request a quote
We reply within 24 hours
Overview
Siemens 5SU13246FA25 is listed under Electrical Components / RCDs & RCBOs. Sales unit: pcs; Power loss: 7.6 W; Rated voltage: 230 V; Rated insulation voltage Ui: 264 V; Rated current: 25 A; Rated fault current: 0.03 A.
Technical Specifications
- Manufacturer part number (MPN)
- 5SU13246FA25
- EAN / GTIN
- 4001869305851
- Sales unit
- pcs
- Power loss
- 7.6 W
- Number of poles (total)
- 2
- Number of protected poles
- 2
- Rated voltage
- 230 V
- Rated insulation voltage Ui
- 264 V
- Rated impulse withstand voltage Uimp
- 4 kV
- Rated current
- 25 A
- Rated fault current
- 0.03 A
- Leakage current type
- A
- Rated short-circuit breaking capacity according to EN 60898
- 10 kA
- Current limiting class
- 3
- Rated short-circuit breaking capacity according to EN 61009
- 10 kA
- Disconnection characteristic
- Undelayed
- Surge current capacity
- 1 kA
- Voltage type
- AC
- Frequency
- 50 Hz
- Release characteristic
- B
- Concurrently switching neutral conductor
- Yes
- With interlocking device
- Yes
- Overvoltage category
- 3
- Pollution degree
- 2
- Ambient temperature during operating
- -25–55 °C
- Width in number of modular spacings
- 3
- Built-in depth
- 70 mm
- Anti-nuisance tripping version
- Yes
- Degree of protection (IP)
- IP20
- Connectable conductor cross section solid-core
- 0.75–35 mm²
- Connectable conductor cross section multi-wired
- 0.75–35 mm²
- Flush-mounted installation
- Yes
- Mounting method
- DIN rail
- Country of origin
- Romania
Standards & Compliance
- HS Code
- 8536.20
Cross References
- EAN 4001869305851
- SAP 1000076474
- Code 8794633
Product Documentation
