Siemens Residual Current Block for MCBs 3P 63 A 30 mA
Pricing
Request a quote
We reply within 24 hours
Product Description
Siemens 5SM2335-6KK01 residual current block for miniature circuit breakers, 3-pole, 63 A, 30 mA. Type A leakage current, 400 V, 50/60 Hz, IP20, pollution degree 2; connectable conductor cross-section 1.5-25 mm² solid or multi-wired. Anti-nuisance tripping version. HS code 8536.90.
Technical Specifications
- Manufacturer part number (MPN)
- 5SM2335-6KK01
- EAN / GTIN
- 4001869357140
- HS code
- 8536.90
- Sales unit
- pcs
- Nominal voltage
- 400 V
- Nominal current
- 63 A
- Rated fault current adjustable
- No
- Rated fault current
- 30 A
- Delay adjustable
- No
- Number of poles
- 3
- Leakage current type
- A
- Surge current capacity
- 4000 kA
- Frequency
- 50/60 Hz
- Rated insulation voltage Ui
- 460 V
- Rated impulse withstand voltage Uimp
- 3 kV
- Connectable conductor cross section solid-core
- 1.5–25 mm²
- Connectable conductor cross section multi-wired
- 1.5–25 mm²
- Anti-nuisance tripping version
- Yes
- With interlocking device
- No
- Degree of protection (IP)
- IP20
- Pollution degree
- 2
- Ambient temperature during operating
- -25–45 °C
- Country of origin
- Czechia
Standards & Compliance
- HS Code
- 8536.90
Cross References
- EAN 4001869357140
- SAP 1200358519
- Code 82369772
Product Documentation
