SG Armaturen
TV Outlet White (78900)
Part number78900EAN / GTIN7021987890012HS code8517.69
Lighting & Electrical Accessories
LED Lights
MOQ:1
Pricing
Request a quote
We reply within 24 hours
Product Description
SG Armaturen 78900 TV outlet white.
Technical Specifications
- Manufacturer part number (MPN)
- 78900
- EAN / GTIN
- 7021987890012
- Sales unit
- pcs
- Package quantity
- 6 pcs
- Mounting
- Indoor
- Housing
- Polycarbonat (PC)
- Colour
- White (RAL 9003)
- Halogen free
- Yes
- Frame
- included 1x1
- Length (mm) L
- 84
- Width (mm) W
- 84
- Height (mm) H
- 33
- Weight (kg) gross/net
- 0.128 / 0.108
- Packaging dimensions (mm)
- 84 x 84 x 33
- Number per pack
- 6
- Mounting method
- Flush-mounted
- Model
- End socket
- Cover
- Central cover plate
- Surface protection
- Untreated
- Frequency
- 47–862 MHz
- Number of outlets
- 2
- Through loss at 860 MHz
- 2 dB
- Tap loss at 860 MHz
- 10 dB
- Material quality
- Thermoplastic
- Suitable for cable modem
- No
- Suitable for remote power supply
- No
- Material
- Plastic
- Type of fastening
- Mounting with screw
- Type of socket outlet
- TV
- Tap loss at 2150 MHz
- 10 dB
- Through loss at 2150 MHz
- 2 dB
- RAL-number (similar)
- 9003
- Degree of protection (IP)
- IP00
- Surface finishing
- Matt
- Device width
- 84 mm
- Device height
- 84 mm
- Device depth
- 33 mm
- Number of modules (module system)
- 1
- DAB+
- No
- Min. depth of built-in installation box
- 22 mm
- TV frequency band
- 5–862 MHz
- Radio frequency band
- 5–862 MHz
- Anti-bacterial treatment
- No
- Country of origin
- China
Standards & Compliance
- HS Code
- 8517.69
Cross References
- EAN 7021987890012
- SAP 1200495877
- Code 82623827
Product Documentation
Document preview: TV Outlet White (78900) — Specification sheet
