SG Armaturen Place Wall Luminaire Black IP54
Pricing
Request a quote
We reply within 24 hours
Product Description
SG Armaturen Place wall luminaire in black with a 20% gloss powder-coated aluminium housing and an opal plastic diffuser. The 350 x 175 x 150 mm fixture is rated IP66 for outdoor use, IK10 for impact and Class II for electrical safety, at 220-240 V AC. Rated life is L90/B10 50,000 h at 25 degC and CRI is 80-89.
Technical Specifications
- Manufacturer part number (MPN)
- 8249044492
- EAN / GTIN
- 5703821174701
- Sales unit
- pcs
- IP rating
- IP54
- IP Class
- IP66
- Mounting
- Wall, Outdoor
- Housing
- Aluminium
- Colour
- Black (20% gloss)
- Length (mm) L
- 350
- Width (mm) W
- 175
- Height (mm) H
- 150
- Weight (kg) gross/net
- 2.5 / 2.3
- Packaging dimensions (mm)
- 390 x 175 x 225
- Mounting method
- Wall bracket
- Protection class according to IEC 61140
- II
- Width
- 175 mm
- Housing colour
- Black
- Surface protection
- Powder coating
- Voltage type
- AC
- Type of control gear
- LED operating device current-controlled
- Colour rendering index CRI
- 80-89
- Length
- 350 mm
- Height/depth
- 150 mm
- Housing material
- Aluminium
- Material
- Aluminium
- Material cover
- Plastic, opal
- Impact strength
- IK10
- With connection cable
- Yes
- Nominal voltage
- 220–240 V
- Degree of protection (IP)
- IP66
- With light source
- No
- With control gear
- No
- Adjustable optics
- No
- Suitable for spigot size
- 60 mm
- Remote control
- None
- With radio control
- No
- With light regulation program control
- No
- Constant light output (CLO)
- No
- IFTTT support available
- No
- Type of wiring
- Ending
- Rated life time L90/B10 at 25 °C
- 50000 h
- Rated ambient temperature according to IEC 62722-2-1
- 25 °C
- Dimming 0-10 V
- No
- Dimming 1-10 V
- No
- Dimming DALI
- No
- Dimming DMX
- No
- Dimming potentiometer (integrated)
- No
- Dimming GPRS
- No
- Dimming LineSwitch
- No
- Dimming manufacturer's proprietary system
- No
- Dimming mains voltage modulation
- No
- Dimming phase cut-off (trailing edge)
- No
- Dimming phase cut-on (leading edge)
- No
- Dimming programmable
- No
- Dimming RF
- No
- Dimming Sine Wave Reduction
- No
- Dimming Touch and Dim
- No
- Dimming Zigbee
- No
- Dimming with push-button
- No
- No dim function
- No
- Dimming DSI
- No
- Energy efficiency class of the built-in lamp
- A++, A+, A (LED)
- Highest energy efficiency class of the exchangeable lamp
- A++
- Lowest energy efficiency class of the exchangeable lamp
- A
- Operation by Bluetooth
- No
- Compatible with Apple HomeKit
- No
- Compatible with Google Assistant
- No
- Compatible with Amazon Alexa
- No
- Exchangeable control gear
- No
- Country of origin
- Denmark
Standards & Compliance
- HS Code
- 9405.99
Cross References
- EAN 5703821174701
- SAP 1200056168
- Code 81904688
Product Documentation
