ARCO AIR R Graphite GU10 6 W LED Outdoor Luminaire

SG Armaturen 623621 ARCO AIR R outdoor wall luminaire, graphite, GU10 6 W LED — the reflector spreads the light gently downwards without glare.

Manufacturer part number (MPN)

623621

EAN / GTIN

7021986236217

Sales unit

pcs

Package quantity

6 pcs

Power

6 W

Efficacy

13 lm/W

Lumen

75lm

IP Class

IP54

Colour temperature

2700K

Colour rendering (Ra)

Ra>90

Lifetime

50,000 L70/B50>

Mounting

Pole, wall, bollard or earthing rod, Outdoor

System wattage

6W

Voltage

220-240V

Type of light source

LED

Socket

GU10

Light source included

Yes

Luminous flux

75lm

MacAdams factor

SDCM: 2

Light distribution

Direct/Indirect

Optic

Glass Clear

Beam angle

360°

UGR

UGR<19

Type

Trailing edge

Luminaire class

Class I

IK Class

IK08

Contains light source of energy class

G

Breeam

Fulfils Hea 01 for flicker free lighting

Housing

Aluminium

Colour

Graphite

Optics

Tempered glass

Connection

Screwless terminal block

Height (mm) H

400

Diameter (mm) D

160

Weight (kg) gross/net

1.992 / 1.66

Packaging dimensions (mm)

185 x 185 x 460

Protection class according to IEC 61140

I

Width

160 mm

Height

400 mm

Conductor cross section

2.5 mm²

With base plate

No

Voltage type

AC

With movement sensor

No

Suitable for lamp power

6 W

Type of control gear

Not required

Colour rendering index CRI

80-89

Diameter

160 mm

With light sensor

No

Luminous intensity

75 cd

Number of poles

2

Length

400 mm

Height/depth

400 mm

Housing material

Aluminium

Lamp type

LED exchangeable

Type of luminaire

Bollard luminaire

Light outlet

Direct/indirect

Material cover

Glass transparent

Impact strength

IK08

Nominal voltage

230–231 V

Degree of protection (IP)

IP54

With light source

Yes

Suitable for number of light sources

1

With control gear

No

Connectable conductor cross section

1.5–2.5 mm²

Max. system power

6 W

Rated luminous flux according to IEC 62722-2-1

75 lm

Colour of light

White

Constant light output (CLO)

No

IFTTT support available

No

Type of wiring

Suitable for loop-through wiring

Rated lifetime L70/B50 at 25 °C

50000 h

Luminaire efficacy

13 lm/W

Energy efficiency class of the built-in lamp

A++, A+, A (LED)

Highest energy efficiency class of the exchangeable lamp

A+

Lowest energy efficiency class of the exchangeable lamp

A+

Compatible with Apple HomeKit

No

Compatible with Google Assistant

No

Compatible with Amazon Alexa

No

Colour of light adjustable

No

Luminous flux adjustable

No

Beam angle adjustable

No

Exchangeable control gear

No

Power factor

0.9

Country of origin

China

HS Code

9405.42

• EAN 7021986236217
• SAP 1200036857
• Code 81595401
