Schneider Magelis HMISTO501 3.4" Mono Touch HMI

Schneider Electric HMISTO501 Magelis STO compact 3.4-inch monochrome touch HMI, 200x80 resolution, 24V DC supply, RS232/485 serial. For small machine operator panels.

Series

Magelis STO, Display Size: 3.4-inch monochrome, Resolution: 200x80, Touch: Resirigide analog touchscreen, Supply Voltage: 24V DC, Communication: 1x RS232/485 serial, 1x USB, Ip Rating: IP65 (front), IP20 (rear), Programming: Vijeo Designer

Range of product

Harmony STO & STU

Product or component type

Touch panel screen

Processor name

CPU RISC

Display size

3.4 inch

Display type

Backlit monochrome STN LCD

Background colour

White, pink and red

Display resolution

200 x 80 pixels

Touch panel

Analogue

Backlight lifespan

10000 hours with red; 50000 hours with pink; 50000 hours with white

Brightness

8 levels

Contrast

16 levels via touch panel

Character font

Korean; Japanese (ANK, Kanji); Taiwanese (traditional Chinese); Chinese (simplified Chinese); ASCII

[Us] rated supply voltage

24 V DC +/- 20 %

Inrush current

30 A

Local signalling

1 LED (green) for normal operation

Power consumption in W

5 W

Number of pages

Limited by internal memory capacity

Processor frequency

333 MHz

Memory description

Application memory 16 MB; Back up of data 128 kB

Integrated connection type

1 USB 2.0 type mini B; 1 USB 2.0 type A; power supply - removable screw terminal block; serial link - 9-pin terminal block - RS232C

Supply

External source

Realtime clock

Access to the PLC real-time clock

Downloadable protocols

Zelio

Range compatibility

Zelio Logic

Fixing mode

By 2 spring clips, mounting on 1.6...5 mm thick panel

Enclosure material

PPT

Marking

CE

Immunity to microbreaks

3 ms

Standards

IEC 61000-6-2; FCC Class A; UL 508; UL 1604; EN 61131-2

Product certifications

CE; UL Class 1 Division 2 T5; UL Class 1 Division 2 T4A; C-Tick; cULus

Ambient air temperature for operation

0…50 °C

Ambient air temperature for storage

-20…60 °C

Relative humidity

0…90 % without condensation

Operating altitude

<= 2000 m

IP degree of protection

IP20 (rear panel) conforming to IEC 60529; IP65 (front panel) conforming to IEC 60529

NEMA degree of protection

NEMA 4X front panel (indoor use)

Shock resistance

15 gn for 11 ms conforming to IEC 60068-2-27

Vibration resistance

+/- 3.5 mm (f = 5…9 Hz) conforming to IEC 60068-2-6; 1 gn (f = 9…150 Hz) conforming to IEC 60068-2-6

Electromagnetic compatibility

Resistance to radiated electromagnetic fields - test level: 10 V/m conforming to IEC 61000-4-3

Country of origin

CN

Warranty (in months)

18

EAN

3595864127835

Standard

IEC 61131-2; UL 508

Classification / Approval

CE, UL, CSA, RCM, EAC

HS Code

8537.10
