Schneider Electric A9XST114 Acti9 Wireless Fridge Temperature Sensor, Set of 4

Schneider Electric A9XST114 is a set of four battery-powered wireless temperature sensors for refrigerators and freezers, part of the Acti9 range. Sensors communicate via Zigbee Green Power at 2.405 GHz to a wireless access point, transmitting a reading every 2 minutes with ±1 °C accuracy over -30 to 55 °C. IP65 enclosure 40 x 40 x 15 mm, mounted by adhesive tape, screws or clamp.

Manufacturer part number (MPN)

A9XST114

EAN / GTIN

3606489904630

HS code

8536.90

Sales unit

pcs

Package quantity

4 pcs

Range

Acti9

Product or component type

Temperature sensor

Product destination

Fridge

Concentrator compatibility

Wireless access point

Range compatibility

Harmony XB5R ZBRA wireless and batteryless range

Colour

White

Communication port protocol

Zigbee green power at 2.405 GHz conforming to IEEE 802.15.4

Maximum radio power

4 dBm

Maximum sensing distance

100 m in free field

Cycle duration

2 min for measuring and transmission

Display type

1 LED (green) for communication status

Supply

Internal battery

fixing mode

Adhesive tape; By 2 screws; By clamp

Standards

IEC 60950; EN 61000-6-1; EN 61000-6-3; EN 61326-1; EN 62311:2007; ETSI EN 301 489-1; ETSI EN 301 489-17; ETSI EN 300 328

Accuracy

+/- 1 °C

Height

15 mm

Width

40 mm

Depth

40 mm

Product weight

15 g

Quantity per set

Set of 4

Product certifications

IC; FCC

IP degree of protection

IP65

Ambient air temperature for operation

-30…55 °C

Relative humidity

0…95 %

Number of Units in Package 1

1

Number of Units in Package 2

12

Warranty (in months)

18

HS Code

8536.90

• EAN 3606489904630
• SAP 1200669984
• Code 83109940
