Schneider Electric SE Back-UPS, 1200VA, Tower, 230V, 6 x IEC C13 outlets, AVR BXS1200MI

Schneider Electric BXS1200MI SE Back-UPS BXS, 1200VA, Tower, 230V, 6 x IEC C13.

Manufacturer part number (MPN)

BXS1200MI

EAN / GTIN

0731304629078

Sales unit

pcs

Main input voltage

230 V AC 1 phase

Cos phi

0.54

Efficiency at full load

140...300 V

Input frequency

50/60 Hz +/- 5 Hz auto-sensing

Output voltage

230 V AC 1 phase

Rated power in W

650 W

Rated power in VA

1200 VA

Output connection

6 IEC 60320 C13

Type of USB power supply

None

Maximum configurable power in VA

1200 VA

Maximum configurable power in W

650 W

Transfer time

6 ms typical : 10 ms maximum

UPS topology

Line interactive

Waveform type

Stepped approximation to a sinewave

Full load runtime

00:01:00 650 W

Half load runtime

00:05:00 300 W

Output frequency

50/60 Hz +/- 1 Hz sync to mains

Run Time

View Runtime Graph

Efficiency

View Efficiency Graph

Battery capacity

9.0 Ah

Battery type

Lead-acid internal included

Control panel

LED Status display with on line : on battery

UPS connectivity

None

Surge energy rating

273 J

Cable length

1.2 m

Number of cables

1

Color

Black

Height

190 mm

Width

140 mm

Depth

390 mm

Product weight

7.6 kg

Mounting preference

No preference

Mounting mode

Not rack-mountable

Two post mountable

0

USB compatible

Yes

Number of power module filled slots

0

Number of power module free slots

0

Redundant

No

Range of product

Back-UPS

Product or component type

Uninterruptible power supply (UPS)

Product certification

CE; CB

Standard

EN/IEC 62040-1:2019/A11:2021

Ambient air temperature for operation

0…40 °C

Ambient air temperature for storage

-15…40 °C

Storage altitude

0…3000 m

IP protection

IP20

Relative humidity

0…95 % non-condensing

Storage relative humidity

0…95 % non-condensing

Acoustic level

40 dBA

Operating altitude

0...3000 m

Battery voltage

12 V

Battery graph comment

Curve fit to measured runtime data. All measurements taken with new, fully charged batteries, at typical environmental conditions, with no electrical input and balanced resistive load (PF = 1.0) output.

Extendable runtime

0

Included battery module

0

Empty battery slot

0

Typical recharge time

8 h

Battery design life

3…5 year(s)

Battery life

3…5 year(s)

Unit Type of Package 1

PCE

Number of Units in Package 1

1

Package 1 Height

30.5 cm

Package 1 Width

23.5 cm

Package 1 Length

49.5 cm

Package 1 Weight

9.1 kg

Unit Type of Package 2

P12

Number of Units in Package 2

49

Package 2 Height

219 cm

Package 2 Width

80 cm

Package 2 Length

120 cm

Package 2 Weight

45.7 kg

Country of origin

CN

Warranty (in months)

24

HS Code

8504.40
