Product Description
Schneider Electric SRTL8KRM4UI APC UPS SRTL Ultra Li-Ion 8kVA 4U Rack/Tower, 230V, in:.
Technical Specifications
- Manufacturer part number (MPN)
- SRTL8KRM4UI
- EAN / GTIN
- 0731304578499
- Sales unit
- pcs
- Main input voltage
- 220 V AC 1 phase
- Other input voltage
- 220...240 V
- Input connection
- Hard Wire 3-wire 46 A
- Input frequency
- 40...70 Hz auto-sensing
- Output voltage
- 220 V AC 1 phase
- Other output voltage
- 220/230/240 V
- Rated power in W
- 8000 W
- Rated power in VA
- 8000 VA
- Output connection
- 6 IEC 60320 C13; 6 IEC 60320 C19
- Bypass type
- Internal bypass (automatic and manual)
- Crest factor
- 3 : 1
- Harmonic distortion
- Less than 5 %
- Maximum configurable power in VA
- 8000 VA
- Maximum configurable power in W
- 8000 W
- UPS topology
- On-Line
- Waveform type
- Its wave
- Full load runtime
- 00:07:00 8000 W
- Half load runtime
- 00:15:00 4000 W
- Output frequency
- 50/60 Hz +/- 3 Hz sync to mains
- Run Time
- View Runtime Graph
- Efficiency
- View Efficiency Graph
- Battery type
- Li-Ion (Lithium-Ion) internal included
- Control panel
- Multifunction LCD status and control console
- Emergency power off
- Yes
- Free slot
- 1
- Preinstalled device
- Network management card with environmental monitoring
- Alarm
- Audible and visible alarms : prioritized by severity
- UPS connectivity
- Serial port; USB port; Available expansion slot
- Surge energy rating
- 1410 J
- Number of rack unit
- 4U
- Number of cables
- 1
- Color
- Silver grey
- Height
- 175 mm
- Width
- 432 mm
- Depth
- 832 mm
- Product weight
- 55 kg
- Mounting location
- Front
- Mounting preference
- Lower
- Mounting mode
- Rack-mounted with kit; Tower-mounted with kit
- USB compatible
- Yes
- Mounting position
- Horizontal; Vertical
- Provided equipment
- Temperature probe; USB cable; Rack mounting hardware; Strain relief; Stabilization feet
- Number of power module free slots
- 0
- Additional specification
- High density
- Redundant
- No
- Range of product
- Smart-UPS Ultra
- Product or component type
- Uninterruptible power supply (UPS)
- Product certification
- VDE
- Marking
- CE Mark; UKCA
- Standard
- EN/IEC 62040-1; IEC 62040-2; EN/IEC 62040-2
- Ambient air temperature for operation
- 0…40 °C
- Ambient air temperature for storage
- -15…45 °C
- Storage altitude
- 0…15240 m
- IP protection
- IP20
- Relative humidity
- 0…95 % non-condensing
- Storage relative humidity
- 0…95 % non-condensing
- Acoustic level
- 55 dB
- Heat dissipation
- 1900 Btu/h
- Operating altitude
- 0...10000 ft
- Battery voltage
- 180 V
- Extendable runtime
- 1
- Included battery module
- 0
- Empty battery slot
- 0
- Typical recharge time
- 1.5 h
- RBC quantity
- 2
- Battery life
- 5…10 year(s)
- Battery charging power
- 1200 W rated
- Unit Type of Package 1
- PCE
- Number of Units in Package 1
- 1
- Package 1 Height
- 63 cm
- Package 1 Width
- 65 cm
- Package 1 Length
- 100 cm
- Package 1 Weight
- 88.5 kg
- SCC14
- 1073130457849
- Country of origin
- PH
- Warranty (in months)
- 60
