Schneider Electric APC NetShelter Metered Rack PDU, 0U, 3PH, 22kW 230V 32A or 17.3kW 230V 24A, X30 C13 and X12 C19 outlets, IEC 309 3P+N+PE cord AP8886

Schneider Electric AP8886 APC by Schneider Electric.

Manufacturer part number (MPN)

AP8886

EAN / GTIN

0731304289937

Sales unit

pcs

Presentation

APC Metered Rack Power Distribution Units (PDUs) provide active metering to enable energy optimization and circuit protection. The output and input connections are (30) C13 & (12) C19, and the cable length is 1.83m. User-defined alarm thresholds mitigate risk with real-time local and remote alerts to warn of potential circuit overloads. Metered Rack PDUs provide power utilization data to allow Data Center Managers to make informed decisions on load balancing and right sizing IT environments to lower the total cost of ownership. Metered Rack PDUs include real power monitoring, a temperature/humidity sensor port, locking IEC receptacles, and ultra-low profile circuit breakers. Users can access and configure Metered Rack PDUs through secure Web, SNMP, or Telnet Interfaces which are complimented by APC Centralized Management platforms using InfraStruxure Central, Operations, Capacity, and Energy Efficiency.

Colour

Black

Product or component type

PDU

PDU type

Metered

Cord length

1.82 m

Provided equipment

Installation guide; Rack mounting brackets; Serial configuration cable; Safety guide

Input Voltage

400 V 3 phases

Height

1829 mm

Width

56 mm

Output Voltage

230 V

Depth

51 mm

Product weight

8.72 kg

Mounting location

Side

Mounting preference

No preference

Input Plug Type

IEC 60309 32 A 3P + N + E

mounting mode

Rack-mounted

Rack units

0U

Mounting position

Vertical

Max line current

32 A

Input current limits

32 A

Load capacity

22000 VA

Network frequency

50/60 Hz

Outlet type and quantity

30 IEC 60320 C13 ; 12 IEC 60320 C19

Product certifications

VCCI class A; VDE

Standards

EN 55022 class A; EN 55024; EN 61000-3-2; EN 61000-3-3; FCC part 15 class A; ICES-003

Ambient air temperature for operation

-5…60 °C

Relative humidity

5…95 %

Operating altitude

0...10000 ft

Ambient air temperature for storage

-25…65 °C

Storage Relative Humidity

5…95 %

Storage altitude

0…15240 m

Unit Type of Package 1

PCE

Number of Units in Package 1

1

Package 1 Height

11.00 cm

Package 1 Width

16.40 cm

Package 1 Length

206.00 cm

Package 1 Weight

9.500 kg

Unit Type of Package 2

PAL

Number of Units in Package 2

5

Package 2 Height

23.000 cm

Package 2 Width

120.000 cm

Package 2 Length

202.000 cm

Package 2 Weight

66.000 kg

Country of origin

IN

Warranty (in months)

24

Nominal current

32 A

Mounting direction

Vertical

Electrical connection

Connection cable with plug

Cable length

1.8 m

Number of C13 socket outlets

30

Number of C19 socket outlets

12

Length

51 mm

Supply voltage

400 V

Overvoltage category

1

Interface ethernet

Yes

HS Code

8537.10

• EAN 0731304289937
• SAP 1000455589
• Code 8218063
