Schneider Electric MTN6185-6036 KNX Push-Button Pro T Temperature Sensor Stainless Steel Matt

Schneider Electric MTN6185-6036 SpaceLogic KNX Push-button Pro T with integrated temperature sensor and touchless mode. Merten System Design in matt stainless-steel finish with four function keys and per-channel LED indication. Programmable with ETS4 and higher.

Manufacturer part number (MPN)

MTN6185-6036

EAN / GTIN

3606481047694

Sales unit

pcs

Package quantity

50 pcs

Range

SpaceLogic KNX

Product or component type

Push-button

Bus type

KNX

Main colour tint

Stainless steel

Control type

Touch type; Touchless

Sensor type

Temperature

Device mounting

Flush

Number of FUNCTION keys

4

Function available

Pulse edges trigger 1-, 2-, 4- or 8-bit telegrams; Express setting: Calls up a pre-set configuration; Push-button with 1 to 4 operating buttons; Night mode: LEDs light up with reduced brightness; Programmable with ETS4 and higher; Pulse edges with 2-byte telegrams; With status displays; Blind (single/dual-surface); Backlit symbols; Disable functions; Scene retrieval; Behaviour and brightness of the status displays; 8-bit linear regulator; Switching, toggling, dimming (single/dual-surface); Dismantling protection with accesories; Advanced setting: Individual configuration; Scene saving; Proximity function

Local signalling

1 LED per channel (white/green)

Marking

With symbols

Material

Plastic

Colour tint

Stainless steel

surface treatment

Varnished

Width

71 mm

Height

71 mm

Device presentation

Mechanism with fixing frame and cover plate

IP degree of protection

IP20

Number of Units in Package 1

1

Number of Units in Package 2

50

Warranty (in months)

18

Other bus systems

None

Number of actuation points

4

Number of buttons

1

Material quality

Thermoplastic

Surface protection

Lacquered

Surface finishing

Matt

Colour

Stainless steel

Degree of protection (IP)

IP20

Min. depth of built-in installation box

40 mm

Mounting method

Flush-mounted

Country of origin

Latvia

HS Code

8536.50

• EAN 3606481047694
• SAP 1200535182
• Code 82822623
