Motordrossel 314A X3 IP00
Pricing
Request a quote
We reply within 24 hours
Product Description
Schneider Electric VW3A5105 Motordrossel 314A X3 IP00.
Technical Specifications
- Manufacturer part number (MPN)
- VW3A5105
- EAN / GTIN
- 3389119201520
- Sales unit
- pcs
- Package quantity
- 2 pcs
- IP rating
- IP00
- Product or component type
- Motor choke
- Range compatibility
- Altivar 71Q; Altivar 61Q; Altivar 61; Altivar 71
- Product specific application
- Output filter
- [In] rated current
- 314 A
- Product compatibility
- ATV61HC11N4; ATV61HC13N4; ATV61HC20Y; ATV61HC25Y; ATV61HD55M3X; ATV61HD75M3X; ATV61QC13N4; ATV61QC16N4; ATV61QC16Y; ATV61QC20Y; ATV71HC11N4; ATV71HC13N4; ATV71HC16Y; ATV71HC20Y; ATV71HD55M3X; ATV71HD75M3X; ATV71QC11N4; ATV71QC13N4; ATV71QC13Y; ATV71QC16Y
- nedded quantity
- 3
- Electrical connection
- Tag connector M10
- Maximum motor cable length
- 150 m shielded cable P motor 55…75 kW at 200...240 V 1; 300 m unshielded cable P motor 55…75 kW at 200...240 V 1; 150 m shielded cable P motor 110…132 kW at 380...480 V 1; 250 m unshielded cable P motor 110…132 kW at 380...480 V 1; 150 m shielded cable P motor 160…250 kW at 500...690 V 1; 250 m unshielded cable P motor 160…250 kW at 500...690 V 1; 250 m shielded cable P motor 160…250 kW at 500...690 V 2; 400 m unshielded cable P motor 160…250 kW at 500...690 V 2
- dv/dt
- 500 V/µs max at 400 V; 750 V/µs max at 500 V; 1000 V/µs max at 690 V
- Thermal losses
- 475 W
- maximum drive output frequency
- 100 Hz
- Ambient air temperature for operation
- -10…50 °C
- Product weight
- 32 kg
- IP degree of protection
- IP20 (with kits VW3A9612,613); IP00
- Ambient air temperature for storage
- -25…70 °C
- Number of Units in Package 1
- 1
- Country of origin
- FR
- Warranty (in months)
- 18
- Accessory
- Yes
- Spare part
- No
Standards & Compliance
- HS Code
- 8504.50
Cross References
- EAN 3389119201520
- SAP 1000528306
- Code 8459990
