Schneider Electric plug-in electromechanical relay - 5 mm - 24 V DC - 1 NO ABR7S11

Schneider Electric ABR7S11 Relay 5mm 24VDC, 1N/O, Ith=6A.

Manufacturer part number (MPN)

ABR7S11 EAN / GTIN: 3389110251470 HS code: 8536.90 Sales unit: pcs Package quantity: 4 pcs Voltage: 24 V DC Range of product: Advantys Telefast ABE7 Product or component type: Plug-in electromechanical relay Control circuit type: DC minimum ordered quantity: Set of 4 Width pitch dimension: 5 mm Product compatibility: ABE7R16T111; ABE7R16M111; ABE7P16M111; ABE7P16T111 [Uc] control circuit voltage: 24 V [Ith] conventional free air thermal current: 6 A Contacts type and composition: 1 NO Threshold tripping voltage: 16.8 V at 40 °C Drop-out voltage: 2 V at 20 °C Drop-out current: 0.5 mA at 20 °C Maximum power dissipation per pole: 0.17 W Associated fuse rating: 1 A, fast blow Maximum switching voltage: 250 V AC 50/60 Hz conforming to IEC 60947-5-1; 30 V DC conforming to IEC 60947-5-1 Electrical durability: 500000 cycles, maximum switching current: 2000 mA at 230 V AC-12; 500000 cycles, maximum switching current: 3000 mA at 24 V DC-12; 500000 cycles, maximum switching current: 400 mA at 230 V AC-15; 500000 cycles, maximum switching current: 500 mA at 24 V DC-13 10 ms minimum switching current: 100 mA at >= 5 V Operating rate in Hz: 20 Hz no load; 0.1 Hz at Ie Mechanical durability: 20000000 cycles [Uimp] rated impulse withstand voltage: 6 kV conforming to IEC 60947-1 Product weight: 0.005 kg Max immunity to microbreaks: 1 ms Dielectric strength: 4000 V conforming to IEC 60947-1 Country of origin: LV Warranty (in months): 18

HS Code

8536.90

• EAN 3389110251470
• SAP 1000012628
• Code 898836
