Schneider Electric discrete I/O module Modicon Momentum - 10I / 8O relay 170ADM39030

Schneider Electric discrete In/O module Modicon Momentum - 10I / 8O relay.

Manufacturer part number (MPN)

170ADM39030

EAN / GTIN

3595861147652

HS code

8536.90

Sales unit

pcs

Package quantity

6 pcs

Voltage

24 V DC

Range of product

Modicon Momentum automation platform

Product or component type

Discrete relay I/O base DC

Group of channels

1 group of 10 inputs; 2 groups of 4 outputs

Discrete input number

10

Discrete input logic

Positive

Discrete output number

8

Network frequency

47...63 Hz

Input resistance

4 kOhm

Mechanical durability

30000000 cycles

Protection type

Without protection

Isolation between channels and bus

500 V AC

Terminals description PLC n°1

(1L+)PW_POS; (3)IN_DIS#3; (9)IN_DIS#9; (1)IN_DIS#1; (8)IN_DIS#8; (6)IN_DIS#6; (2)IN_DIS#2; (7)IN_DIS#7; (4)IN_DIS#4; (L+)PW_POS; (10)IN_DIS#10; (5)IN_DIS#5; (M-)PW_NEG; TB

Terminals description PLC n°2

(6)OUT_DIS#6; (2L1)PW; (2)OUT_DIS#2; TB_1; (8)OUT_DIS#8; (7)OUT_DIS#7; (1L+)PW; (4)OUT_DIS#4; (5)OUT_DIS#5; (1)OUT_DIS#1; (3)OUT_DIS#3

Height

141.5 mm

Width

125 mm

Depth

47.5 mm

Product weight

0.26 kg

Protective treatment

TC

Marking

CE

Country of origin

ID

Warranty (in months)

18

HS Code

8536.90

• EAN 3595861147652
• SAP 1000083110
• Code 8833385
