Schneider Electric LV432534 — Escutcheon for toggle, with protection collar, drawout NSX400/630, IP40

Schneider Electric LV432534 is a front-panel escutcheon (door frame) for toggle, with protection collar on drawout ComPacT NSX400/630 (and EasyPact CVS 400/630) moulded-case circuit breakers. It mounts on the switchboard door around the operating face to finish the cut-out and provide IP40 degree of protection at the front face. Conforms to IEC 60947-2 as a circuit-breaker accessory. RoHS 2011/65/EU and REACH compliant; CE marked.

Type

front-panel escutcheon (door frame) for toggle, with protection collar

Compatible devices

ComPacT NSX400/630 (and EasyPact CVS 400/630) (drawout mounting)

Degree of protection

IP40

Function

mounts on the switchboard door around the device operating face; raises the front-face degree of protection and provides a finished cut-out

Standard

IEC 60947-2 (circuit-breaker accessory)

Compliance

RoHS 2011/65/EU, REACH; CE marked

Manufacturer part number (MPN)

LV432534

EAN / GTIN

3606480021473

HS code

8538.90

Product or component type

Escutcheon collar

Accessory / separate part category

Insulation accessory

Range compatibility

ComPact ComPact NSX400; ComPact ComPact NSX630

Control type

Toggle

mounting mode

Drawout

IP degree of protection

IP40 conforming to IEC 60529

Country of origin

FR

Warranty (in months)

18

Standard

IEC 60947-2

HS Code

8538.90

• EAN 3606480021473
• SAP 1000092758
• Code 8860945
