Schneider Electric MN undervoltage release, ComPacT NSX, rated voltage 125 VDC, screwless spring terminal connections LV429413
Pricing
Request a quote
We reply within 24 hours
Product Description
Schneider Electric LV429413 MN 125VDC nullsp.coil =NSX630.
Technical Specifications
- Manufacturer part number (MPN)
- LV429413
- EAN / GTIN
- 3606480019029
- Sales unit
- pcs
- Package quantity
- 10 pcs
- Range
- ComPacT
- Range of product
- ComPact NSX100...250; ComPacT NSX100...250; ComPact NSX400...630; ComPacT NSX400...630; ComPact NSX100...250 DC; ComPacT NSX100...250 DC; ComPact NSX100...250 DC PV; ComPacT NSX100...250 DC PV; ComPact NSX400...630 DC; ComPacT NSX400...630 DC; ComPact NSX400...630 DC PV; ComPacT NSX400...630 DC PV
- Device short name
- MN
- Product or component type
- Voltage release
- Device application
- Control
- Voltage release type
- Opening coil; Undervoltage release
- [Uc] control circuit voltage
- 125 V DC
- Range compatibility
- ComPacT ComPacT NSX; ComPacT ComPacT NSX DC; ComPact ComPact NSX; ComPact ComPact NSX DC; EasyPact EasyPact CVS; PowerPact PowerPact Multistandard
- Operating threshold
- 0.35...0.7 x Un opening; 0.85 x Un closing
- Response time
- 50 ms
- Supply holding power
- 5 W
- Supply inrush power
- 10 W
- Auxiliary connection terminal
- Spring 0.5…1.5 mm² (20 AWG...16 AWG)
- Wire stripping length
- 7 mm
- Number of Units in Package 1
- 1
- Number of Units in Package 2
- 10
- Number of Units in Package 3
- 60
- Country of origin
- PL
- Warranty (in months)
- 18
- Delayed
- No
- Suitable for off-load switch
- Yes
- Suitable for overload relay
- No
- Type of electric connection
- Spring clamp connection
- Rated control supply voltage DC
- 125 V
- Suitable for motor safety switch
- Yes
- Suitable for power circuit breaker
- Yes
- Voltage type for actuating
- DC
Standards & Compliance
- HS Code
- 8536.30
Cross References
- EAN 3606480019029
- SAP 1000092312
- Code 8930292
Product Documentation
More from Schneider Electric
Schneider Electric
Schneider Electric TeSys F - contactor coil - LX1FH - 110...115 V AC 40...400 Hz LX1FH1102
Schneider Electric
WALL-Mount Cabinet WITH WINDOW. 6X6X3
NSYS3D6630T
Schneider Electric
Esmi Impresia Zone Module
FFS06741006
Schneider Electric
Schneider Electric Selector switch, Harmony XB5, grey plastic, black, 22mm, 2 positions, stay put, 1 NO, compact push in terminals XB5AD215
Schneider Electric
Silicone-Button Black 16 MM Vandr
XACB9222
Schneider Electric
Selector switch flush complete long
XB5FJ53
Schneider Electric
Schneider Electric Soft starter, Altistart 480, 480A, 208 to 690V AC, control supply 110 to 230V AC ATS480C48Y
Schneider Electric
Schneider Electric A9F93220 ACTI9 IC60L Miniature Circuit Breaker 2P 20 A, Curve B
Technical guides
Catalogue entry last verified: 2026-09-29. A manufacturer datasheet is attached to this entry — confirm application-critical values against it.
Frequently asked questions
- Where can I buy LV429413?
- LV429413 can be ordered from cballast.com as a Schneider Electric catalogue item: request a quotation on this page or email sales@cballast.com, and the order ships worldwide.
- What is the manufacturer part number for this Schneider Electric product?
- The manufacturer part number is LV429413.
- What is the HS code for LV429413?
- The customs tariff (HS) code for LV429413 is 8536.30.
- Who manufactures LV429413?
- LV429413 is a Schneider Electric product in the Electrical Components range.
- Is a datasheet available for LV429413?
- Yes — the LV429413 datasheet can be viewed and downloaded on this page.
- What is the minimum order quantity for LV429413?
- The minimum order quantity is 1.
- Is LV429413 available?
- Yes — LV429413 is available to order: fulfilment is from supplier stock in cBallast's European network, dispatched directly from the warehouse to the customer, with the exact lead time stated in the quotation (reply within 24 hours).
