Schneider Electric TeSys F - contactor coil - LX1FH - 110...115 V AC 40...400 Hz LX1FH1102
Pricing
Request a quote
We reply within 24 hours
Product Description
Schneider Electric LX1FH1102 coil 110V 50HZ LC1F265-F330.
Technical Specifications
- Manufacturer part number (MPN)
- LX1FH1102
- EAN / GTIN
- 3389110553345
- Sales unit
- pcs
- Package quantity
- 12 pcs
- Voltage
- 110 V
- Frequency
- 50/60 Hz
- Range
- TeSys
- Product or component type
- Contactor coil
- Device short name
- LX1FH
- Range compatibility
- TeSys TeSys F LC1F contactor
- Product compatibility
- LC1F330; LC1F265
- Control circuit type
- AC at 40...400 Hz
- [Uc] control circuit voltage
- 110...115 V AC 40...400 Hz
- Average resistance
- 18.7 Ohm inrush at 20 °C; 440 Ohm holding at 20 °C
- Operating time
- 100...170 ms opening; 40...65 ms closing
- Mechanical durability
- 10 Mcycles
- Maximum operating rate
- 2400 cyc/h 55 °C
- Coil technology
- Without built-in suppressor module
- Control circuit voltage limits
- Drop-out: 0.35...0.55 Uc 40...400 Hz (at 55 °C); Operational: 0.85...1.1 Uc 40...400 Hz (at 55 °C)
- Inrush power in VA
- 650 VA 40...400 Hz cos phi 0.9 (at 20 °C)
- Hold-in power consumption in VA
- 10 VA 40...400 Hz cos phi 0.3 (at 20 °C)
- Heat dissipation
- 8 W at 40...400 Hz
- Ambient air temperature for operation
- -5…55 °C
- Product weight
- 0.75 kg
- Warranty (in months)
- 18
- Rated control supply voltage AC 50 Hz
- 110–115 V
- Rated control supply voltage AC 60 Hz
- 110–115 V
- Voltage type for actuating
- AC
- Country of origin
- Czechia
Standards & Compliance
- HS Code
- 8505.90
Cross References
- EAN 3389110553345
- SAP 1000008155
- Code 881799
