Schneider Electric MicroswitchesOF/SDE/PFANDWIRING-FORMTZ2/MTZ3 LV847905

Schneider Electric LV847905 Microbryter and cable for OF/SDE/PF for Masterpact MTZ2/3 circuit breaker.

Manufacturer part number (MPN)

LV847905 EAN / GTIN: 3606480823374 HS code: 8536.90 Sales unit: pcs Range: MasterPact Device short name: OF; CH; PF; SDE Product or component type: Auxiliary contact block Device application: Control Range compatibility: MasterPact MTZ2 circuit breaker; MasterPact MTZ3 circuit breaker Auxiliary contacts type: Standard Signal contacts composition: 4 NO/NC Breaking capacity: 6 A AC-12 240/380 V AC 50/60 Hz; 2 A AC-12 480 V AC 50/60 Hz; 0.3 A DC-12 125 V DC; 0.15 A DC-12 250 V DC; 3 A AC-12 690 V AC 50/60 Hz minimum load: 100 mA at 24 V Unit Type of Package 1: PCE Number of Units in Package 1: 1 Package 1 Height: 3.000 cm Package 1 Width: 8.000 cm Package 1 Length: 8.000 cm Package 1 Weight: 17.000 g Unit Type of Package 2: BB1 Number of Units in Package 2: 8 Package 2 Height: 6.000 cm Package 2 Width: 18.000 cm Package 2 Length: 26.500 cm Package 2 Weight: 221.000 g Unit Type of Package 3: S03 Number of Units in Package 3: 64 Package 3 Height: 30.000 cm Package 3 Width: 30.000 cm Package 3 Length: 40.000 cm Package 3 Weight: 1.552 kg Country of origin: FR Warranty (in months): 18

HS Code

8536.90

• EAN 3606480823374
• SAP 1200050802
• Code 81878609
