Voltagesfors.modVPS M.logic X
Pricing
Request a quote
We reply within 24 hours
Product Description
Schneider Electric LV850060 Spenningsforsyningsmodul VPS for Micrologic X protection.
Technical Specifications
- Manufacturer part number (MPN)
- LV850060
- EAN / GTIN
- 3606480933042
- Sales unit
- pcs
- Package quantity
- 48 pcs
- Range
- MasterPacT
- Device short name
- VPS
- Product or component type
- Power supply
- Range compatibility
- MasterPact MasterPact MTZ1 circuit breaker; MasterPact MasterPact MTZ2 circuit breaker; MasterPact MasterPact MTZ3 circuit breaker
- mounting mode
- Fixed
- Product destination
- inside of the front panel control unit
- Trip unit name
- MicroLogic 2.0 X; MicroLogic 5.0 X; MicroLogic 6.0 X; MicroLogic 7.0 X
- Overvoltage category
- IV
- [Us] rated supply voltage
- 208...600 V AC 50...60 Hz tolerance: + 10 % - 15 %
- Output voltage
- 24 V DC +/- 8 %
- Power consumption in W
- 2.6 W
- Network number of phases
- 3 phases; 2 phases
- Height
- 22 mm
- Width
- 45 mm
- Depth
- 65 mm
- Unit Type of Package 1
- PCE
- Number of Units in Package 1
- 1
- Package 1 Height
- 4.600 cm
- Package 1 Width
- 6.000 cm
- Package 1 Length
- 8.200 cm
- Package 1 Weight
- 61.200 g
- Unit Type of Package 2
- BB1
- Number of Units in Package 2
- 8
- Package 2 Height
- 8.800 cm
- Package 2 Width
- 13.000 cm
- Package 2 Length
- 18.700 cm
- Package 2 Weight
- 531.000 g
- Unit Type of Package 3
- S02
- Number of Units in Package 3
- 48
- Package 3 Height
- 15.000 cm
- Package 3 Width
- 30.000 cm
- Package 3 Length
- 40.000 cm
- Package 3 Weight
- 3.286 kg
- Country of origin
- FR
- Warranty (in months)
- 18
Standards & Compliance
- HS Code
- 8538.90
Cross References
- EAN 3606480933042
- SAP 1200050801
- Code 81878633
Product Documentation
