Schneider Electric LV833756 Masterpact MTZ Low-Level CE Auxiliary Contact Disconnected Position

Schneider Electric LV833756 is a low-level CE auxiliary contact signalling the disconnected position for drawout Masterpact MTZ1, MTZ2 and MTZ3 circuit breakers. Supplied as a 1 NO/NC signal contact for control-circuit indication with a minimum load of 2 mA at 15 V. Rated 5 A AC-12 up to 380 V and up to 2.5 A DC-12 at 24/48 V. Classified under HS code 8536.90 and manufactured in France.

Manufacturer part number (MPN)

LV833756 EAN / GTIN: 3606480803727 HS code: 8536.90 Sales unit: pcs Range: MasterPact Device short name: CD Product or component type: Auxiliary contact Device application: Control Range compatibility: Masterpact MasterPact MTZ1 circuit breaker; Masterpact MasterPact MTZ2 circuit breaker; Masterpact MasterPact MTZ3 circuit breaker Signal contacts composition: 1 NO/NC mounting mode: Drawout Auxiliary contacts type: Low level Auxiliary contacts operation: Disconnected position [Ie] rated operational current: DC-12: 0.3 A at 250 V DC; DC-12: 0.8 A at 125 V DC; DC-12: 2.5 A at 24/48 V DC; AC-12: 5 A at 24/48 V AC 50/60 Hz; AC-12: 5 A at 240 V AC 50/60 Hz; AC-12: 5 A at 380 V AC 50/60 Hz minimum load: 2 mA at 15 V Number of Units in Package 1: 1 Country of origin: FR Warranty (in months): 18

HS Code

8536.90

• EAN 3606480803727
• SAP 1200050339
• Code 81878915
