NW 10 H1 3P Withdrawable
Pricing
Request a quote
We reply within 24 hours
Product Description
Schneider Electric 48245 NW 10 H1 3P Withdrawable.
Technical Specifications
- Manufacturer part number (MPN)
- 48245
- EAN / GTIN
- 3303430482451
- Sales unit
- pcs
- Number of poles
- 3P
- Rated permanent current Iu
- 1000 A
- With integrated under voltage release
- No
- Number of auxiliary contacts as change-over contact
- 5
- Rated voltage
- 690 V
- Power loss
- 150 W
- Degree of protection (IP)
- IP30
- Position of connection for main current circuit
- Back side
- Motor drive integrated
- No
- Type of electrical connection of main circuit
- Bolt connection
- Type of control element
- Push button
- With switched-off indicator
- Yes
- Rated short-circuit breaking capacity Icu at 400 V, 50 Hz
- 65 kA
- Suitable for DIN rail (top hat rail) mounting
- No
- Integrated earth fault protection
- No
- Motor drive optional
- Yes
- Device construction
- Built-in device slide-in technique (withdrawable)
- DIN rail (top hat rail) mounting optional
- No
- Complete device with protection unit
- No
- Country of origin
- France
Standards & Compliance
- HS Code
- 8536.20
Cross References
- EAN 3303430482451
- SAP 1200497972
- Code 82639514
Product Documentation
