Schneider Electric Thermal magnetic circuit breaker, TeSys GB2, 1P+N, 10 A, Icu 1.5 kA@240 V GB2CD16
Pricing
Request a quote
We reply within 24 hours
Product Description
Schneider Electric GB2CD16 Fuse aut Control current 2P 10A.
Technical Specifications
- Manufacturer part number (MPN)
- GB2CD16
- EAN / GTIN
- 3389110214956
- HS code
- 8536.90
- Sales unit
- pcs
- Package quantity
- 6 pcs
- Rated current
- 10 A
- Number of poles
- 2P
- Range
- TeSys
- Product name
- TeSys GB2
- Device short name
- GB2
- Product or component type
- Circuit breaker
- Device application
- Control
- Poles description
- 1P + N
- Network type
- AC/DC
- Utilisation category
- Category A conforming to IEC 60947-2; DC-12 conforming to IEC 60947-5-1; DC-13 conforming to IEC 60947-5-1
- Network frequency
- 50/60 Hz conforming to IEC 60947-2
- Breaking capacity
- 1 kA Icu at 230/240 V AC 50/60 Hz conforming to IEC 60947-2
- [Ics] rated service short-circuit breaking capacity
- 75 % at 230/240 V AC 50/60 Hz conforming to IEC 60947-2
- Trip unit technology
- Thermal-magnetic
- Magnetic tripping current
- 138 A
- mounting mode
- By clips
- Mounting support
- Plate; Rail
- Mounting position
- Horizontal; Vertical
- Control type
- Toggle
- [In] rated current
- 10 A
- [Ue] rated operational voltage
- 250 V AC 50/60 Hz conforming to IEC 60947-2; 277 V AC 60 Hz conforming to CSA C22.2 No 235; 277 V AC 60 Hz conforming to UL 1077; 48 V DC
- [Uimp] rated impulse withstand voltage
- 4 kV conforming to IEC 60947-2
- Power dissipation per pole
- 2 W
- Mechanical durability
- 8000 cycles
- Electrical durability
- 8000 cycles
- Connections - terminals
- Connector 1 cable(s) 0.75…6 mm²solid without cable end; Connector 2 cable(s) 0.75…4 mm²solid without cable end; Connector 1 cable(s) 0.75…4 mm²flexible with cable end; Connector 2 cable(s) 0.75…2.5 mm²flexible with cable end
- Tightening torque
- 1.2 N.m on connector
- Mechanical robustness
- Shocks: 22 Gn for 20 ms conforming to IEC 60068-2-27; Vibrations: 5 Gn, 5...110 Hz conforming to IEC 60068-2-6
- Quantity per set
- Set of 6
- 9 mm pitches
- 2
- Height
- 74 mm
- Width
- 15 mm
- Depth
- 67 mm
- Product weight
- 0.07 kg
- Standards
- EN/IEC 60947-1; EN/IEC 60947-2; CSA C22.2 No 235; UL 1077
- Product certifications
- UL; CSA
- Protective treatment
- TC
- IP degree of protection
- IP20 conforming to IEC 60529
- Ambient air temperature for operation
- -20…60 °C
- Ambient air temperature for storage
- -40…80 °C
- Fire resistance
- 960 °C conforming to IEC 60695-2-1
- Operating altitude
- 3000 m
- Country of origin
- FR
- Warranty (in months)
- 18
