Schneider Electric LV429521 External Neutral Current Transformer NSX 25-100 A

Schneider Electric LV429521 is an external neutral current transformer for three-pole ComPact NSX100 breakers fitted with Micrologic 5 or 6 trip units, enabling neutral-conductor measurement and protection. Rated primary 25-100 A / secondary 5 A, 1.6 VA, accuracy class 1. Through-feed design with screw secondary connection and contact protection.

Manufacturer part number (MPN)

LV429521

EAN / GTIN

3606480018886

Sales unit

pcs

Product or component type

Neutral sensor

Device application

Power supply

Range compatibility

ComPact ComPact NSX100

[In] rated current

25…100 A

Unit Type of Package 1

PCE

Number of Units in Package 1

1

Package 1 Height

11.000 cm

Package 1 Width

11.000 cm

Package 1 Length

24.000 cm

Package 1 Weight

460.000 g

Unit Type of Package 2

S03

Number of Units in Package 2

6

Package 2 Height

30.000 cm

Package 2 Width

30.000 cm

Package 2 Length

40.000 cm

Package 2 Weight

3.247 kg

Country of origin

FR

Warranty (in months)

18

Power consumption

1.6 W

Model

Through-feed current converter

Rated primary current

100 A

Rated secondary current

5 A

Rated secondary apparent power

1.6 VA

Accuracy class

1

Calibrated

Yes

With contact protection

Yes

Snap mounting

No

With copper rail

Yes

Number of primary inputs

1

Secondary connection

Screw connection

HS Code

8504.31

• EAN 3606480018886
• SAP 1200791583
• Code 83955510
