Schneider Electric shunt trip (spring) MX - 380...415 V AC 50HZ- 440...480 V AC 60Hz LV426846
Pricing
Request a quote
We reply within 24 hours
Product Description
Schneider Electric LV426846 Shunttrippspole MX 380-480V AC for ComPact NSXm circuit breaker.
Technical Specifications
- Manufacturer part number (MPN)
- LV426846
- EAN / GTIN
- 3606485413099
- HS code
- 8536.90
- Sales unit
- pcs
- Package quantity
- 20 pcs
- Voltage
- 380-480 V AC
- Range
- ComPact
- Range of product
- ComPacT NSXm
- Device short name
- MX
- Product or component type
- Voltage release
- Device application
- Control
- Voltage release type
- Opening coil; Shunt trip release
- Control type
- Standard
- [Uc] control circuit voltage
- 380...415 V AC 50 Hz; 440...480 V AC 60 Hz
- Range compatibility
- ComPact ComPacT NSXm; ComPact ComPact NSXm; PowerPact PowerPact B
- Operating threshold
- 0.7 Un opening
- Response time
- < 50 ms
- Control signal type
- Impulse; Maintained
- Impulse duration
- >= 20 ms
- Auxiliary connection terminal
- Spring
- Country of origin
- FR
- Warranty (in months)
- 18
Standards & Compliance
- HS Code
- 8536.90
Cross References
- EAN 3606485413099
- SAP 1200323254
- Code 82306346
Product Documentation
