Schneider Electric Socket, 6 A, relay type SSL, spring terminals, 5/24 V DC SSLZRA1

Schneider Electric SSLZRA1 Spring plinth 6 A 24VDC.

Manufacturer part number (MPN)

SSLZRA1

EAN / GTIN

3606480580161

Sales unit

pcs

Package quantity

10 pcs

Range of product

Harmony Solid State Relays

Device short name

SSLZ

Product or component type

Socket for SSL1

Product compatibility

Solid state relay SSL with NO contact at 24 V DC; Solid state relay SSL with NO contact at 5 V DC

[Ith] conventional free air thermal current

6 A

Switching voltage

5 V DC; 24 V DC

[Ue] rated operational voltage

< 250 V DC

Shape of pin

Flat

Contact terminal arrangement

Separate

Connections - terminals

Spring terminals, 1 x 0.2...1 x 1.5 mm² (24 AWG...16 AWG) solid without cable end; Spring terminals, 1 x 0.2...1 x 1.5 mm² (24 AWG...16 AWG) flexible with cable end

Clamping force

10…40 N

Fixing mode

Clip-on (35 mm DIN rail)

[Uimp] rated impulse withstand voltage

3.6 kV

Overvoltage category

III

Pollution degree

3

Sale per indivisible quantity

10

Local signalling

LED (green) for input status

Width

6.2 mm

Height

103 mm

Depth

78.6 mm

Product weight

0.0285 kg

Standards

IEC 61984

Product certifications

UL 508; CSA C22-2 No 14

Marking

CE

Ambient air temperature for storage

-40…85 °C

Ambient air temperature for operation

-40…70 °C

IP degree of protection

IP20

Flame retardance

V0 conforming to UL 94

Unit Type of Package 1

PCE

Number of Units in Package 1

1

Package 1 Height

0.600 cm

Package 1 Width

8.000 cm

Package 1 Length

10.500 cm

Package 1 Weight

23.000 g

Unit Type of Package 2

BB1

Number of Units in Package 2

10

Package 2 Height

8.500 cm

Package 2 Width

7.100 cm

Package 2 Length

10.700 cm

Package 2 Weight

252.000 g

Unit Type of Package 3

S03

Number of Units in Package 3

300

Package 3 Height

30.000 cm

Package 3 Width

30.000 cm

Package 3 Length

40.000 cm

Package 3 Weight

8.280 kg

Country of origin

CN

Warranty (in months)

18

Mounting method

DIN rail (top hat rail) 35 mm

With detachable clamps

No

Function extension possible

No

Type of electric connection

Spring clamp connection

Number of pins

8

HS Code

8536.90
