RC-Joint 24-48VAC (LAD4RCE)
Pricing
Request a quote
We reply within 24 hours
Product Description
Schneider Electric LAD4RCE Rc-Element 24-48VAC.
Technical Specifications
- Manufacturer part number (MPN)
- LAD4RCE
- EAN / GTIN
- 3389110385199
- Sales unit
- pcs
- Package quantity
- 10 pcs
- Voltage
- 24-48 V AC
- Range
- TeSys
- Device short name
- LAD4
- Product or component type
- Suppressor module
- Product compatibility
- 3P LC1D09...D38; 4P LC1DT20...DT40; 4P LC1D098...D258; CAD32, CAD50
- Mounting location
- Side
- mounting mode
- By clips
- Suppressor technology
- RC circuit
- [Uc] control circuit voltage
- 24...48 V AC
- Maximum peak voltage
- 3 Uc
- Product weight
- 0.012 kg
- Standards
- IEC 60947-5-1; EN 60947-5-1; CSA C22.2 No 60947-5-1; UL 60947-5-1; GB/T 14048.5
- Product certifications
- UL; CSA
- IP degree of protection
- IP2X conforming to IEC 60529
- Ambient air temperature for operation
- -25…55 °C
- Ambient air temperature for storage
- -40…80 °C
- Number of Units in Package 1
- 1
- Number of Units in Package 2
- 70
- Number of Units in Package 3
- 2240
- Country of origin
- FR
- Warranty (in months)
- 18
- Function
- RC-element
- Rated control supply voltage AC 50 Hz
- 24–48 V
- Rated control supply voltage AC 60 Hz
- 24–48 V
- Voltage type (operating voltage)
- AC
- With LED indication
- No
- Operating voltage AC 50 Hz
- 24–48 V
- Operating voltage AC 60 Hz
- 24–48 V
- Voltage type for actuating
- AC
Standards & Compliance
- HS Code
- 8536.30
Cross References
- EAN 3389110385199
- SAP 1000042939
- Code 8775248
Product Documentation
