Schneider Electric TeSys D - auxiliary contact block - 3 NO + 1 NC - screw clamp terminals LA1DZ31

Schneider Electric LA1DZ31 Auxiliary block 2NO+1NO/1NC IP 54.

Manufacturer part number (MPN)

LA1DZ31 EAN / GTIN: 3389110236521 Sales unit: pcs IP rating: IP54 Range: TeSys Product name: TeSys Deca Product or component type: Auxiliary contact block Device short name: LA1 Range compatibility: TeSys D CAD; TeSys D LC1D; TeSys F LC1F; TeSys F CR1F; TeSys Deca CAD; TeSys Deca LC1D Mounting location: Front Pole contact composition: 2 NO (sealed) + 1 NO + 1 NC Contacts operation: Instantaneous [Ue] rated operational voltage: 125 V AC for protected contact; 30 V DC for protected contact; 690 V AC for non-protected contact [Ie] rated operational current: 0.1 A for protected contact [Ui] rated insulation voltage: 250 V - for protected contact conforming to IEC 60947-5-1; 690 V - for non-protected contact conforming to IEC 60947-5-1; 600 V - for non-protected contact conforming to UL 60947-5-1; 600 V - for non-protected contact conforming to CSA C22.2 No 60947-5-1 [Ith] conventional free air thermal current: 10 A (at 40 °C) for non-protected contact Standards: EN/IEC 60947-5-1; UL 60947-5-1; CSA C22.2 No 60947-5-1; GB/T 14048.5 Product certifications: CB; UL; CSA; CCC; EAC; UKCA Protection type: GG fuse 10 A for non-protected contact Mechanical durability: 5 Mcycles minimum switching current: 1 mA for protected contact; 5 mA for non-protected contact minimum switching voltage: 5 V for protected contact; 17 V for non-protected contact Insulation resistance: > 10 MOhm Connections - terminals: Screw clamp terminals 1 cable(s) 1…2.5 mm²flexible with cable end; Screw clamp terminals 1 cable(s) 1…2.5 mm²flexible without cable end; Screw clamp terminals 2 cable(s) 1…2.5 mm²flexible with cable end; Screw clamp terminals 2 cable(s) 1…2.5 mm²flexible without cable end; Screw clamp terminals 1 cable(s) 1…2.5 mm²rigid; Screw clamp terminals 2 cable(s) 1…2.5 mm²rigid Tightening torque: 1.7 N.m - with screwdriver flat Ø 6 mm; 1.7 N.m - with screwdriver Philips No 2; 1.7 N.m - with screwdriver pozidriv No 2 Height: 48 mm Width: 44 mm Depth: 39 mm Environmental characteristic: Harsh environment IP degree of protection: IP2X conforming to IEC 60529 Protective treatment: TH conforming to IEC 60068 Ambient air temperature for storage: -25…70 °C Ambient air temperature for operation: -25…70 °C Number of Units in Package 1: 1 Number of Units in Package 2: 80 Country of origin: CZ Warranty (in months): 18

HS Code

8538.90

• EAN 3389110236521
• SAP 1000016177
• Code 8136024
