Schneider Electric braking resistor - IP 20 - 28 Ohm - 200 W VW3A7703
Pricing
Request a quote
We reply within 24 hours
Product Description
Schneider Electric VW3A7703 Braking resistor 28 ohm 200W.
Technical Specifications
- Manufacturer part number (MPN)
- VW3A7703
- EAN / GTIN
- 3389118065758
- Sales unit
- pcs
- Power
- 200 W
- Resistance
- 28 Ω
- Range of product
- Altivar
- Range compatibility
- Altivar 61; Altivar 312; Altivar 32; Altivar 312 Solar; Altivar 31C
- Product compatibility
- ATV312HD11N4; ATV312HD11S6; ATV312HD15N4; ATV312HD15S6; ATV312HU40M3; ATV31CD11N4; ATV31CD15N4; ATV32HD11N4; ATV32HD15N4; ATV61HD18Y; ATV61HD22Y; ATV61HU30M3; ATV61HU40M3; ATV61WD15N4; ATV61WD15N4C; ATV61WD18N4; ATV61WD18N4C; ATV71HD11N4; ATV71HD15N4; ATV71HD15Y; ATV71HD18Y; ATV71HU30M3; ATV71HU40M3; ATV71PD11N4Z; ATV71WD11N4; ATV71WD15N4; Variable speed drive ATV310 at 11 kW
- Ohmic value
- 28 Ohm
- [Ue] rated operational voltage
- 24 V DC at 0.1 A; 250 V AC at 1 A
- Average power available
- 200 W at 50 °C; 231 W at 40 °C
- Electrical connection
- terminal, connection capacity: <= 1.5 mm² / 16 AWG for temperature control switch; terminal, connection capacity: <= 4 mm² / 28 AWG for drive
- temperature controlled switch contact resistance
- 60 µOhm
- Protection type
- Thermal protection via drive or temperature control switch at 120 °C
- Width
- 140 mm
- Height
- 393 mm
- Depth
- 120 mm
- Product weight
- 3.5 kg
- IP degree of protection
- IP20
- Ambient air temperature for storage
- -25…70 °C
- Ambient air temperature for operation
- 0…50 °C
- Number of Units in Package 1
- 1
- Number of Units in Package 2
- 6
- Country of origin
- DE
- Warranty (in months)
- 18
- Type of accessory/spare part
- Breaking resistance
- Accessory
- Yes
- Spare part
- No
Standards & Compliance
- HS Code
- 8533.29
Cross References
- EAN 3389118065758
- SAP 1000254554
- Code 8222685
