Schneider Electric Acti9 iACTp Overvoltage Protection Auxiliary 220-240 V AC A9C15920

Schneider Electric A9C15920 is an Acti9 iACTp overvoltage protection auxiliary for two circuits, operating on 220-240 V AC at 50/60 Hz with a hold-in consumption of 3 VA. It mounts on a 35 mm DIN rail fixed to the left of an iCT contactor, occupying 2 x 9 mm pitches with tunnel-type control terminals. Suited to Acti9 iCT distribution assemblies in small commercial and residential installations, it carries IP20 protection and complies with IEC/EN 61095.

Manufacturer part number (MPN)

A9C15920

EAN / GTIN

3606480097904

Sales unit

pcs

Package quantity

12 pcs

Voltage

230 V

Range

Acti9

Product or component type

Overvoltage protection auxiliary (2 circuits)

Device short name

iACTp

[Uc] control circuit voltage

220...240 V AC 50/60 Hz

Hold-in power consumption in VA

3 VA

mounting mode

Fixed, on the left of CT

Mounting support

DIN rail

9 mm pitches

2

Height

81 mm

Width

18 mm

Depth

60 mm

Colour

White

Overvoltage category

III

[Uimp] rated impulse withstand voltage

4 kV

[Ui] rated insulation voltage

440 V

Standards

IEC/EN 61095

Connections - terminals

Control circuit: tunnel type terminals 2 cable(s) 2.5 mm² flexible; Control circuit: tunnel type terminals 2 cable(s) 1.5 mm² rigid; Control circuit: tunnel type terminals 1 cable(s) 1.5…2.5 mm² rigid; Control circuit: tunnel type terminals 1 cable(s) 1.5…2.5 mm² flexible with ferrule; Control circuit: yellow clips

Wire stripping length

9 mm

Tightening torque

0.8 N.m

Range compatibility

Acti9 iCT

Market segment

Small commercial; Residential

Compatibility code

IACTp

IP degree of protection

IP20 conforming to IEC 60529

Ambient air temperature for operation

-5…50 °C

Ambient air temperature for storage

40…70 °C

Number of Units in Package 1

1

Number of Units in Package 2

12

Number of Units in Package 3

108

Warranty (in months)

18

Function

RC-element

Rated control supply voltage AC 50 Hz

220–240 V

Rated control supply voltage AC 60 Hz

220–240 V

Voltage type (operating voltage)

AC

With LED indication

No

Operating voltage AC 50 Hz

220–240 V

Operating voltage AC 60 Hz

220–240 V

Voltage type for actuating

AC

Country of origin

France

HS Code

8548.90
