Schneider Electric Modular timing relay, 5 A, 2 CO, 0.1 S..100 h, on-Delay, 230 V AC REXL2TMP7

Schneider Electric REXL2TMP7 MiniReleFors.in 2c/o5A 230VAC.

Manufacturer part number (MPN)

REXL2TMP7 EAN / GTIN: 3389119400053 Sales unit: pcs Package quantity: 48 pcs Voltage: 230 V AC Range of product: Harmony Timer Relays Fixing mode: Plug-in (socket) Product or component type: Miniature timing relay Discrete output type: Relay Contacts type and composition: 2 C/O Component name: REXL Time delay type: Power on-delay Time delay range: 10...100 h; 1...10 min; 1...10 h; 0.1...1 s; 6...60 min; 6...60 s; 1...10 s Width: 21 mm Contacts material: Cadmium free [Us] rated supply voltage: 230 V AC 50/60 Hz Voltage range: 0.85...1.15 Us [In] rated current: 5 A AC Repeat accuracy: +/- 0.5 % Setting accuracy of time delay: 10 % at full scale at 25 °C conforming to IEC 61812-1 Temperature drift: 0.05 %/°C maximum reset time: 250 ms after time delay, on de-energisation; 50 ms during time delay, on de-energisation Voltage drift: +/- 0.2 %/V Maximum switching capacity: 4 x 5 A maximum temporary permissible current: 10 A for < 10 s minimum switching current: 100 mA Electrical durability: 100000 cycles at 250 V AC resistive Mechanical durability: 10000000 cycles maximum power consumption: 3 VA [Ui] rated insulation voltage: 250 V conforming to IEC 255 Group C; 250 V conforming to VDE 0010 Output overvoltage protection: 2 J Surge withstand: 2 kV conforming to IEC 61000-4-5 level 3 Creepage distance: 4 kV/3 conforming to IEC 60664-1 Local signalling: 1 LED (red) for output in operation; 1 LED (yellow) for power ON Function available: A- Power on-delay relay-2 C/O Control type: Without test button Shape of pin: Flat Number of functions: 1 Product weight: 0.05 kg Immunity to microbreaks: 5 ms Dielectric strength: 2 kV for 1 mA/1 minute at 50 Hz conforming to IEC 60601-1; 2 kV for 1 mA/1 minute at 50 Hz conforming to IEC 61812-1 Standards: IEC 60601-1; 89/336/EEC; IEC 61000-6-2; EN 50081-2; IEC 61812-1; 73/23/EEC; IEC 60601-2; 93/68/EEC Product certifications: UL; cUL Ambient air temperature for operation: -20…60 °C Ambient air temperature for storage: -40…70 °C IP degree of protection: IP50 conforming to IEC 60529 Vibration resistance: 0.35 mm (f= 10…55 Hz) conforming to IEC 60068-2-6 Relative humidity: 95 % without condensation conforming to IEC 60068-2-6 Resistance to electrostatic discharge: 6 kV in contact conforming to IEC 61000-4-2 level 3; 8 kV in air conforming to IEC 61000-4-2 level 3 Resistance to electromagnetic fields: 10 V/m conforming to IEC 61000-4-3 level 3 Resistance to fast transients: 2 kV conforming to IEC 61000-4-4 level 3 Immunity to radioelectric fields: 10 V (0.15...80 MHz) conforming to IEC 61000-4-6 level 3 Immunity to voltage dips: >= 95 % / 1 s conforming to IEC 61000-4-11; 30 % / 10 ms conforming to IEC 61000-4-11; 60 % / 100 ms conforming to IEC 61000-4-11 Disturbance radiated/conducted: Class B conforming to EN 55022 (EN 55011 group 1) Number of Units in Package 1: 1 Number of Units in Package 2: 48 Country of origin: ID Warranty (in months): 18 Complete with socket: No Type of electric connection: Plug-in connection Function delay-on energization: Yes Function delay on de-energization: No Function floating contact on energization: No Function floating contact on de-energization: No Function star-delta: No Function pulse shaping: No Function flashing, starting with pause, fixed time: No Function flashing, starting with pulse, fixed time: No Clock function, starting with pause, variable: No Clock function, starting with pulse, variable: No With plug-in socket: Yes Remote operation possible: No Suitable as remote control: No Pluggable on auxiliary contact block: No Rated control supply voltage AC 50 Hz: 230 V Rated control supply voltage AC 60 Hz: 230 V Voltage type for actuating: AC Nominal current: 5 A Time range: 0.1–360000 s Number of outputs, delayed, change-over contact: 2 Outputs, reversible delayed/undelayed: No With semiconductor output: No Suitable for DIN rail (top hat rail) mounting: No Suitable for front mounting: No Height: 27 mm Depth: 63 mm

HS Code

8536.49

• EAN 3389119400053
• SAP 1000661676
• Code 8495729
