Motordrossel 759A X3 IP00

Schneider Electric VW3A5107 Motordrossel 759A (X3) IP00.

Manufacturer part number (MPN)

VW3A5107

EAN / GTIN

3389119201544

Sales unit

pcs

IP rating

IP00

Product or component type

Motor choke

Range compatibility

Altivar 71; Altivar Process ATV900; Altivar 61Q; Altivar 61; Altivar 71Q; Altivar Process ATV600

Product specific application

Output filter

[In] rated current

759 A

Product compatibility

ATV71HC25N4; ATV61HC25N4; ATV61HC31N4; ATV61HC40N4; ATV61HC50Y; ATV61HC63Y; ATV61QC31N4; ATV61QC40N4; ATV61QC40Y; ATV61QC50Y; ATV71HC28N4; ATV71HC31N4; ATV71HC40N4; ATV71HC40Y; ATV71HC50Y; ATV71QC25N4; ATV71QC31N4; ATV71QC31Y; ATV71QC40Y; ATV630 variable speed drive wall mount - 250 kW, 380...480 V; ATV630 variable speed drive wall mount - 315 kW, 380...480 V; ATV930 variable speed drive wall mount - 250 kW, 380...480 V; ATV930 variable speed drive wall mount - 315 kW, 380...480 V

nedded quantity

3

Electrical connection

Tag connector 2 x M12

Maximum motor cable length

200 m shielded cable P motor 250…355 kW at 380...480 V 1; 250 m unshielded cable P motor 250…355 kW at 380...480 V 1; 150 m shielded cable P motor 400…630 kW at 500...690 V 1; 250 m unshielded cable P motor 400…630 kW at 500...690 V 1; 250 m shielded cable P motor 400…630 kW at 500...690 V 2; 400 m unshielded cable P motor 400…630 kW at 500...690 V 2

dv/dt

500 V/µs max at 400 V; 750 V/µs max at 500 V; 1000 V/µs max at 690 V

Thermal losses

598 W

maximum drive output frequency

100 Hz

Ambient air temperature for operation

-10…50 °C

Product weight

93 kg

IP degree of protection

IP20 (with kits VW3A9612,613); IP00

Ambient air temperature for storage

-25…70 °C

Number of Units in Package 1

1

Country of origin

CN

Warranty (in months)

18

Accessory

Yes

Spare part

No

HS Code

8504.50
