Bakelitt mounting plate 1000X800
Pricing
Request a quote
We reply within 24 hours
Product Description
Schneider Electric NSYMB108 bakelite mounting plate 1000x800.
Technical Specifications
- Manufacturer part number (MPN)
- NSYMB108
- EAN / GTIN
- 3606480182662
- Sales unit
- pcs
- Dimensions
- 1000×800 mm
- Range
- PanelSeT
- Accessory / separate part category
- Mounting accessory
- Product or component type
- Mounting plate
- Device application
- Multi-purpose
- Enclosure nominal dimensions
- - H: 800 mm W: 1000 mm ; - H: 1000 mm W: 800 mm
- Mounting location
- Step slide; Direct fixing on backstuds
- Mounting plate description
- Plain
- Range compatibility
- PanelSeT S3D; PanelSeT CRN; PanelSeT PLM PLM
- Quantity per set
- Set of 1
- Material
- Bakelite
- Colour
- Black (RAL 9005)
- Fixing mode
- Screwed on backstuds - screw type M8; By fixing element
- Permanent permissible load
- 200 kg
- Height
- 965 mm
- Width
- 750 mm
- thickness
- 5 mm
- Product weight
- 57 kg
- Number of Units in Package 1
- 1
- Number of Units in Package 2
- 50
- Country of origin
- ES
- Warranty (in months)
- 18
- Perforated
- No
- Surface protection
- Untreated
Standards & Compliance
- HS Code
- 3926.90
Cross References
- EAN 3606480182662
- SAP 1000317925
- Code 8823776
Product Documentation
